Testing Printer Operation

You can print the hardware configuration test label to test the printer and make
sure it is operating correctly. The hardware configuration test label lists your
printer's configuration. Use this label for reference when connecting the 3240
printer to your system.
Note: For the entire hardware configuration label to print out, you must use media
that is at least 2.6 inches wide.
To print the hardware configuration test label
1. Turn the On/Off switch to the off position.
2. Press and hold the Feed/Pause button while turning the printer power on.
3. Release the Feed/Pause button when the media starts moving. The printer
4. Turn the printer power off and then on to enter Print mode.
3240 Hardware Configuration
Memory Installed
Mileage
Printhead
Hardware Options
Firmware Checksum
Program : 063103
C o d e 39
The Alert and Empty/Pause LEDs blink during the printer self-test.
feeds out one or two blank labels (to verify the label length) and then prints
the hardware configuration test label.
Storage RAM : 128 kilobytes
Image RAM : 375 kilobytes
Flash RAM : none
Inches Processed : 36
Inches Burned
: 12
Width : 1024 dots
Dot Size : 2.5 mil
Burn Pot Setting : 231
I/O Option : none
Internal Option
: none
External Option : Self Strip
ROM0 (U9) : CDE3 ROM1 (U8): 0A1E
VERSION: 0.9
