- Page 1 Reference Manual DOC. REV. 11/30/2010 EPM-15 (Manx) AMD LX Based SBC with Ethernet, Video, and PC/104- Plus interface...
- Page 2 Copyright © 2013 VersaLogic Corp. All rights reserved. Notice: Although every effort has been made to ensure this document is error-free, VersaLogic makes no representations or warranties with respect to this product and specifically disclaims any implied warranties of merchantability or fitness for any particular purpose.
- Page 3 Data sheets and manufacturers’ links for chips used in this product BIOS information and upgrades Utility routines and benchmark software Note: This is a private page for EPM-15 users that can be accessed only be entering this address directly. It cannot be reached from the VersaLogic homepage. EPM-15 Reference manual...
-
Page 4: Table Of Contents
CMOS Setup ........................11 Operating System Installation................... 12 Physical Details ......................13 Dimensions ........................13 EPM-15 Dimensions and Mounting Holes ............13 CBR-5010 Dimensions and Mounting Holes ............14 Hardware Assembly..................... 15 Stack Arrangement Example ................15 EPM-15 External Connectors ................... 16 EPM-15 Connector Locations –... - Page 5 PC/104 Memory Support ..................38 IRQ Support......................38 DMA Support ...................... 38 System Resources and Maps..................39 Memory Map ........................39 I/O Map..........................39 Interrupt Configuration ..................... 40 Special Registers ......................41 Special Control Register ....................41 Revision Indicator Register....................42 EPM-15 Reference manual...
- Page 6 Contents Jumper and Status Register....................43 RS-485/422 Transmit/Receive Control Register .............. 44 Appendix A – References ..................... 45 Appendix B – Generated Frequencies ................ 46 EPM-15 Reference Manual...
-
Page 7: Introduction
5V supply to the USB ports. EPM-15 boards are subjected to 100% functional testing and are backed by a limited two-year warranty. Careful parts sourcing and US-based technical support ensure the highest possible quality, reliability, service and product longevity for this exceptional SBC. -
Page 8: Technical Specifications
IDE Interface: Embedded-PCI (PC/104-Plus) – full compliance, One-channel, 44-pin, 2mm connector. Supports 3.3V signaling up to and including ATA 100. Weight: Supports two Parallel ATA IDE devices (hard 0.254 lbs (0.115 kg) drive, CD-ROM, CF, etc.) EPM-15 Reference Manual... -
Page 9: Epm-15 Block Diagrams
Introduction EPM-15 Block Diagrams SDRAM Address, Data, Control Analog RGB FP LVDS National SDCLKS Digital RGB DS90C383A FS2 JTAG Pads System Clocking (MK1491-09) 14.318 MHz Intel 33 MHz 24.576 MHz 10/100M Audio 25.000 MHz USB 2.0 CS5536 (4 Ports) I/O Companion 48.000 MHz... - Page 10 CPU VCORE 1.2V @ 200 mA LTC3025 CS5536 VCORE 3.3V @ 1.4A LTC3412 CPU and CS5536 VIO I809 POR TO CS5536 EIRQ1_3V (EXTERNAL WAKE) PWRBTN# (SOFT PWR BUTTON) PWR CONTROL WORK_AUX Figure 2. Power Control Block Diagram EPM-15 Reference Manual...
-
Page 11: Rohs Compliance
(PBDE) flame retardants, in certain electrical and electronic products sold in the European Union (EU) beginning July 1, 2006. VersaLogic Corporation is committed to supporting customers with high-quality products and services meeting the European Union’s RoHS directive. -
Page 12: Handling Care
CMOS RAM to become corrupted through careless handling (such as when changing the CompactFlash module), resulting in CMOS resetting to factory defaults. EPM-15 Reference Manual... -
Page 13: Technical Support
Introduction Technical Support If you are unable to solve a problem after reading this manual please visit the EPM-15 Product Support web page shown below. If you have further questions, contact VersaLogic technical support at (541) 485-8575. VersaLogic technical support engineers are also available via e-mail at Support@VersaLogic.com. -
Page 14: Configuration And Setup
Inspect the system visually for any damaged that may have occurred in shipping. Contact Support@VersaLogic.com immediately if any items are damaged or missing. Gather all the peripheral devices you plan to attach to the EPM-15 and their interface and power cables. - Page 15 OS Installation Drive CD-ROM Power Drives Figure 3. EPM-15 Typical Start-up Configuration 1. Attach Power Plug the power adapter cable CBR-1008 into socket J9. Attach the motherboard connector of the ATX power supply to the adapter. 2. Attach Cables and Peripherals Plug the video adapter cable CBR-1201 into socket J1.
- Page 16 Configuration and Setup 3. Review Configuration Before you power up the system, double check all the connections. Make sure all cables are oriented correctly and that adequate power will be supplied to the EPM-15 and peripheral devices. 4. Power On Turn on the ATX power supply and the video monitor.
-
Page 17: Cmos Setup
Configuration and Setup CMOS Setup The default CMOS Setup parameters for the EPM-15 are shown below. Basic CMOS Configuration +------------------------------------------------------------------------------+ System BIOS Setup - Basic CMOS Configuration (C) 2005 General Software, Inc. All rights reserved +---------------------------+--------------------+-----------------------------+ | DRIVE ASSIGNMENT ORDER: | Date:>Apr 09, 2009 | Typematic Delay... -
Page 18: Operating System Installation
Operating System Installation The standard PC architecture used on the EPM-15 makes the installation and use of most of the standard x86 processor-based operating systems very simple. The operating systems listed on the... -
Page 19: Physical Details
Physical Details Dimensions EPM-15 D IMENSIONS AND OUNTING OLES The EPM-15 complies with all PC/104-Plus standards. Dimensions are given below to help with pre-production planning and layout. All dimensions are in inches. Drawings are not to scale. 3.575 3.375 3.275 3.175 0.200... -
Page 20: Cbr-5010 Dimensions And Mounting Holes
Physical Details CBR-5010 D IMENSIONS AND OUNTING OLES 5.50 5.10 1.575 1.875 1.175 1.95 1.38 0.065 Figure 5. CBR-5010 Dimensions EPM-15 Reference Manual... -
Page 21: Hardware Assembly
ARDWARE SSEMBLY The EPM-15 uses pass-through PC/104 and PC/104-Plus connectors so that expansion modules can be added to the top or bottom of the stack. PC/104 (ISA) modules must not be positioned between the EPM-15 and any PC/104-Plus (PCI) modules on the stack. -
Page 22: Epm-15 External Connectors
Physical Details EPM-15 External Connectors Ethernet PC/104-Plus Audio Battery Standard I/O Video (COM, USB, Output timer inputs, reset, LED, speaker) CompactFlash PC/104 Main Power = Pin 1 Figure 7. EPM-15 Connector Locations (Top) EPM-15 Reference Manual... -
Page 23: Epm-15 Connector Locations - Bottom
Physical Details EPM-15 C – B ONNECTOR OCATIONS OTTOM PC-104-Plus (PCI) pass-through male LVDS PC-104 (ISA) pass-through male = Pin 1 Figure 8. EPM-15 Connector Locations (Bottom) EPM-15 Reference Manual... -
Page 24: Epm-15 Connector Functions And Interface Cables
UNCTIONS AND NTERFACE ABLES Table 1 provides information about the function, mating connectors, and transition cables for EPM-15 connectors. Page numbers indicate where a detailed pinout or further information is available. Table 1: EPM-15 Connector Functions and Interface Cables Transition... -
Page 25: Breakout Board Connectors
2mm, 50-pin, keyed, latching header ACPI Pushbutton Input Conta-Clip 10250.4 5-pin screw terminal COM1 Kycon K42-E9P/P-A4N DB-9 male USB 0-3 USB Type A USB Type A COM4 Conta-Clip 10250.4 5-pin screw terminal COM3 Conta-Clip 10250.4 5-pin screw terminal EPM-15 Reference Manual... -
Page 26: Jumper Blocks
Physical Details Jumper Blocks UMPERS HIPPED ONFIGURATION (or V5 Figure 10. Jumper Block Locations * Jumper block V1 was labeled V5 on revision 3.xx and earlier boards. EPM-15 Reference Manual... -
Page 27: Jumper Summary
Battery Power Jumper [1-2] In – Standard Operation [2-3] In – Erase CMOS Warning: Use care when handling the EPM-15 not to short the V2 pins accidentally, which may cause CMOS to revert to factory settings. COM3 RS-422/485 Termination In – Line A and B terminated with 127 Ohms Out –... -
Page 28: System Features
Power Supply OWER ONNECTORS Main power is applied to the EPM-15 through a 10-pin polarized connector, with mating connector Berg 69176-010 (Housing) + Berg 47715-000 (Pins). See the table below for connector pinout and Figure 7 for location information. Warning! To prevent severe and possibly irreparable damage to the system, it is critical that the power connectors are wired correctly. -
Page 29: Power Requirements
CMOS RAM and the Real-Time Clock. When clearing CMOS RAM: 1) Power off the EPM-15. 2) Install the jumper on V2[2-3] and leave it for four seconds. 3) Move the jumper to back to V2[1-2]. 4) Power on the EPM-15. -
Page 30: Cmos Setup Defaults
System Features CMOS Setup Defaults The EPM-15 permits users to modify CMOS Setup defaults. This allows the system to boot up with user-defined settings from cleared or corrupted CMOS RAM, battery failure or battery-less operation. All CMOS setup defaults can be changed, except the time and date. CMOS Setup defaults can be updated with the BIOS Update Utility. -
Page 31: Acpi Power Management
System Features ACPI Power Management The EPM-15 supports the Advanced Configuration and Power Interface (ACPI) “S3 Sleeping State,” also known as “suspend to RAM” mode. Wakeup is accomplished by grounding pin 39 to pin 40 on connector J8 or via pushbutton (or relay attached to the pushbutton interface). Power consumption in standby mode is under 1 watt. -
Page 32: Wakeup
A pushbutton or relay can be attached to connector J2 on the CBR-5010 utility board. Pin 3 is ground, and pin 4 is the pushbutton input. This circuit on the EPM-15 motherboard has a 10k pull-up resistor. EPM-15 Reference Manual... -
Page 33: Interfaces And Connectors
Interfaces and Connectors Serial Ports The EPM-15 features three on-board 16550-based serial channels located at standard PC I/O addresses. Connector J8 provides interfaces to the COM ports. See Table 6 for COM port signal and pinout information. COM1 is an RS-232 (115.2K baud) serial port. COM3 and COM4 can be operated in RS-422 or RS-485 modes. -
Page 34: Ide Hard Drive / Cd-Rom Interfaces
DD14 Data bus bit 14 Chip select 1 Data bus bit 0 DASP- DD15 Data bus bit 15 Ground Ground Ground Ground Power +5.0 V Power +5.0 V PDMARQ DMA request Ground Ground Ground Ground No connection EPM-15 Reference Manual... -
Page 35: J8 Utility Connector
+5V (Protected) Speaker RxD+ TxD/RxD+ Speaker Drive RxD– TxD/RxD– Ground PBRESET – Ground Ground Pushbutton Reset USB0 Ground +5V (Protected) Channel 0 Data + Channel 0 Data - Note: Do not connect to these pins in RS-485 mode. EPM-15 Reference Manual... -
Page 36: Usb Interface
USB I NTERFACE Connector J8 includes interfaces for four USB ports. The USB interface on the EPM-15 is UHCI (Universal Host Controller Interface) and EHCI (Enhance Host Controller Interface) compatible, which provides a common industry software/hardware interface. There are four USB connectors on the CBR-5010 breakout board. -
Page 37: Parallel Port
Interfaces and Connectors Parallel Port The EPM-15 includes a standard bi-directional/EPP/ECP compatible LPT port which resides at the PC standard address of 378h. The port can be enabled or disabled and interrupt assignments can be made via CMOS Setup. The LPT mode is also set via CMOS Setup. -
Page 38: Video Interface
Interfaces and Connectors Video Interface An on-board video controller integrated into the chipset provides high performance video output for the EPM-15. (The EPM-15 can also be operated without video card attached. See “Console Redirection.”) ONFIGURATION The EPM-15 uses a shared-memory architecture. This allows the video controller to use 16 MB of system DRAM for video RAM. -
Page 39: Lvds Flat Panel Display Connector
ISPLAY ONNECTOR The integrated LVDS Flat Panel Display in the EPM-15 is an ANSI/TIA/EIA-644-1995 specification-compliant interface. It can support up to 24 bits of RGB pixel data plus 3 bits of timing control (HSYNC/VSYNC/DE) on the 4 differential data output pairs. The LVDS clock frequency ranges from 25 MHz to 85 MHz. -
Page 40: Compatible Lvds Panel Displays
Compatible with DOS or Windows Generic VGA driver, but not the GX Windows driver. ONSOLE EDIRECTION The EPM-15 can be operated without using the onboard video output by redirecting the console to COM1. CMOS Setup and some operating systems such as DOS can use this console for user interaction. - Page 41 The following diagram illustrates a typical DB9 to DB9 RS-232 null modem adapter. System 1 <--> System 2 Name Name ------------------------------------ <--> <--> <--> <--> <--> <--> Pins 7 and 8 are shorted together on each connector. Unlisted pins have no connection. EPM-15 Reference Manual...
-
Page 42: Ethernet Interface
Interfaces and Connectors Ethernet Interface The EPM-15 features an on-board Ethernet controller. For the EPM-15g and h, the controller is the Intel 82551ER Fast Ethernet controller. For the EPM-15S and E, the controller is the Intel 82541ER controller. While these controllers are not NE2000-compatible, they are widely supported. -
Page 43: Audio
Interfaces and Connectors Audio The audio interface on the EPM-15 is implemented using the Analog Devices AD1981B Audio Codec (EPM-15g, h) or the National Semiconductor LM4549B (EPM-15S, E). This interface is AC ’97 2.1 compatible. Drivers are available for most Windows-based operating systems. To obtain the most current versions, consult the EPM-15 product support page. -
Page 44: Pc/104 Expansion Bus
Interfaces and Connectors PC/104 Expansion Bus EPM-15 has limited support of the PC/104 bus. Most PC/104 cards will work, but be sure to check the requirements of your PC/104 card against the list below. PC/104 I/O S UPPORT The following I/O ranges are supported: 100h –... -
Page 45: System Resources And Maps
System Resources and Maps Memory Map The lower 1 MB memory map of the EPM-15 is arranged as shown in the following table. Various blocks of memory space between C0000h and FFFFFh can be shadowed. The CMOS setup is used to enable or disable this feature. -
Page 46: Interrupt Configuration
IRQ4 are normally used by COM ports on the main board.) Though the EPM-15 is not equipped with a standard keyboard (IRQ1), floppy disk (IRQ6), or mouse (IRQ12), the BIOS infrastructure makes it appear they exist for DOS and older operating systems. -
Page 47: Special Registers
Temperature Status Indicates CPU temperature. CPU temperature is below value set in the CMOS setup CPU temperature is above value set in the CMOS setup This bit is read-only. D4-D0 Reserved Reserved — These bits have no function. EPM-15 Reference Manual... -
Page 48: Revision Indicator Register
Special Registers Revision Indicator Register REVIND (READ ONLY) 1D1h REV1 REV0 This register is used to indicate the revision level of the EPM-15. Table 17: Revision Indicator Register Bit Assignments Mnemonic Description D7-D3 Product Code — These bits are hard-coded to represent the product type. The EPM-15 always reads as 00011. -
Page 49: Jumper And Status Register
This bit is read-only. SB-SEL System BIOS Selection — Indicates the status of jumper. Jumper out, Master System BIOS selected. Jumper in, Run Time System BIOS selected. This bit is read-only. D4-D0 Reserved Reserved — These bits have no function. EPM-15 Reference Manual... -
Page 50: Rs-485/422 Transmit/Receive Control Register
COM3 RS-485/422 Receive Enable — Controls RS-485/422 Rx on COM3. COM3RE4XX Disable RS-485/422 receiver on COM3. Enable RS-485/422 receiver on COM3. COM3 RS-422 Transmit Enable — Controls RS-422 Tx on COM3. COM3TE422 Disable RS-422 transmitter on COM3. Enable RS-422 transmitter on COM3. EPM-15 Reference Manual... -
Page 51: Appendix A - References
Intel 82541ER Video Controller In chipset. PC/104 Specification PC/104 Consortium PC/104 Resource Guide PC/104-Plus Specification VersaLogic Corporation PC/104 Resource Guide General PC Documentation Microsoft Press The Programmer’s PC Sourcebook General PC Documentation Powell’s Books The Undocumented PC EPM-15 Reference Manual... -
Page 52: Appendix B - Generated Frequencies
Appendix B – Generated Frequencies The following frequencies on the EPM-15 board can be measured for EMI/EMC testing. Table 20: Generated Frequencies Component Frequencies Notes 10/100 Ethernet 25 MHz Y1 crystal, U7 82551ER chip. 32.768 kHz Y2 crystal, U13A CS5536 chip.
