- Page 1 Reference Manual DOC. REV. 8/23/2010 EPM-14 (Cougar) AMD LX 800 Based SBC with Ethernet, Video, and PC/104-Plus Interface...
- Page 2 Copyright © 2013 VersaLogic Corp. All rights reserved. Notice: Although every effort has been made to ensure this document is error-free, VersaLogic makes no representations or warranties with respect to this product and specifically disclaims any implied warranties of merchantability or fitness for any particular purpose.
- Page 3 Beta release. Rev 1 Release Pre-production only. No customer shipments. Support Page The EPM-14 support page, at http://www.versalogic.com/private/cougarsupport.asp, contains additional information and resources for this product including: Reference Manual (PDF format) Operating system information and software drivers Data sheets and manufacturers’ links for chips used in this product...
-
Page 4: Table Of Contents
Contents Introduction ........................1 Description.......................... 1 Technical Specifications ..................... 2 EPM-14 Block Diagram ..................... 3 RoHS-Compliance ......................4 About RoHS......................4 Warnings..........................4 Electrostatic Discharge ..................4 Lithium Battery...................... 4 Transient Voltage Suppression (TVS) Devices ............. 5 Technical Support ....................... 6 Repair Service...................... - Page 5 Contents Real Time Clock ....................... 24 Setting the Clock....................24 Interfaces and Connectors ................... 25 Utility I/O Connector J7 ....................25 IDE............................ 26 Serial Ports........................27 COM Port Configuration ..................27 Serial Port Connectors ..................27 COM3 RS-422/485 Line Driver Control ............. 28 USB...........................
-
Page 6: Introduction
Introduction Description The EPM-14 is a feature-packed single board computer designed for OEM control projects requiring fast processing and designed-in reliability and longevity (product lifespan). Its features include: AMD LX 800 microcontroller TVS devices on user I/O connections with CS5536 companion chip (require connection to earth ground) 256 MB system RAM, soldered Three COM ports (two RS-232, one... -
Page 7: Technical Specifications
Introduction Technical Specifications Specifications are typical at 25°C with 5.0V supply unless otherwise noted. Board Size: COM1–2 Interface: 4.250" x 3.775" (PC/104 compliant) RS-232, 16C550 compatible, 115k baud max. Storage Temperature: COM3 Interface: -40° C to 85° C RS-422/RS-485, 16C550 compatible, 460k Free Air Operating Temperature: baud max. -
Page 8: Epm-14 Block Diagram
Introduction EPM-14 Block Diagram Video Analog CRT CBR-1201 DDRAM LX 800 LVDS TTL to LVDS CBR-2010 or CBR-2011 Ethernet RJ45 10/100 Ethernet RJ45 10/100 PC/104+ (PCI) Speaker, LED, Reset CS5536 44-pin IDE I/O Companion USB 2.0 (4 Ports) CompactFlash CPLD PC/104 (ISA) ISA Bridge BIOS... -
Page 9: Rohs-Compliance
(PBDE) flame retardants, in certain electrical and electronic products sold in the European Union (EU) beginning July 1, 2006. VersaLogic Corporation is committed to supporting customers with high-quality products and services meeting the European Union’s RoHS directive. -
Page 10: Transient Voltage Suppression (Tvs) Devices
Introduction (TVS) D RANSIENT OLTAGE UPPRESSION EVICES The EPM-14 circuitry is protected from spike and surge damage by on-board transient voltage suppression (TVS) devices on the user I/O signals. Figure 2 shows a typical example of TVS circuitry. In order for the TVS devices to function properly, they must be connected to earth ground. -
Page 11: Technical Support
If you are unable to solve a problem with this manual please visit the EPM-14 Product Support web page listed below. If you have further questions, contact VersaLogic technical support at (503) 747-2261. VersaLogic technical support engineers are also available via e-mail at Support@VersaLogic.com. -
Page 12: Configuration And Setup
Inspect the system visually for any damage that may have occurred in shipping. Contact Support@VersaLogic.com immediately if any items are damaged or missing. Gather all the peripheral devices you plan to attach to the EPM-14 and their interface and power cables. - Page 13 Configuration and Setup CBR– 1201 Analog SVGA USB Keyboard CBR- 5011 EPM-14 “Cougar” USB Mouse CD- ROM OS Installation CBR– 1008 Drive CD-ROM Hard Drive Power Supply Figure 4. Typical Start-up Configuration 1. Attach Cables and Peripherals Plug the video adapter cable CBR-1201 into socket J4. Attach the video monitor interface cable to the video adapter.
- Page 14 Configuration and Setup 2. Attach Power Plug the power adapter cable CBR-1008 into connector J10. Attach the motherboard connector of the ATX power supply to the adapter. 3. Review Configuration Before you power up the system, double check all the connections. Make sure all cables are oriented correctly and that adequate power will be supplied to the EPM-14 and peripheral devices.
-
Page 15: Cmos Setup
Configuration and Setup CMOS Setup The default CMOS Setup parameters for the EPM-14 are shown below. Basic CMOS Configuration +------------------------------------------------------------------------------+ System Bios Setup - Basic CMOS Configuration (C) 2005 General Software, Inc. All rights reserved +---------------------------+--------------------+-----------------------------+ | DRIVE ASSIGNMENT ORDER: | Date:>May 06, 2008 | Typematic Delay : 250 ms | Drive A: (None) -
Page 16: Operating System Installation
The standard PC architecture used on the EPM-14 makes the installation and use of most of the standard x86 processor-based operating systems very simple. The operating systems listed on the VersaLogic OS Compatibility Chart use the standard installation procedures provided by the maker of the OS. -
Page 17: Physical Details
Physical Details Dimensions and Mounting The EPM-14 complies with all EBX standards which provide for specific mounting hole and PC/104-Plus stack locations as shown in the diagram below. 3.575 3.375 3.275 3.175 0.125 DIA x4 Use 3mm or #4 standoffs 0.200 0.100 0.000... - Page 18 Physical Details 0.50 0.06 0.44 Figure 6. EPM-14 Height Dimensions (Not to scale. All dimensions in inches.) 5.50 5.10 1.57 1.87 1.17 1.38 0.06 Figure 7. CBR-5011 Dimensions and Mounting Holes EPM-14 Reference Manual...
-
Page 19: Hardware Assembly
Physical Details ARDWARE SSEMBLY The EPM-14 uses PC/104 and PC/104-Plus connectors so that expansion modules can be added to the top of the stack. PC/104 (ISA) modules must not be positioned between the EPM-14 and any PC/104-Plus (PCI) modules on the stack. The entire assembly can sit on a table top or be secured to a base plate. -
Page 20: External Connectors
Physical Details External Connectors EPM-14 C ONNECTORS Earth Ground Reference Point Ethernet 1 Ethernet 0 PC/104-Plus Battery SVGA CompactFlash COM 1-3, USB 1-4, PC/104 Power PLED, IDE LED, Reset Button, Speaker = Pin 1 Figure 9. EPM-14 Connectors – Top Side EPM-14 Reference Manual... - Page 21 Physical Details LVDS = Pin 1 Figure 10. EPM-14 Connectors – Bottom Side EPM-14 Reference Manual...
-
Page 22: Epm-14 Connector Functions And Interface Cables
Physical Details EPM-14 C ONNECTOR UNCTIONS AND NTERFACE ABLES The following table notes the function of each connector, as well as mating connectors and cables, and the page where a detailed pinout or further information is available. Table 1: Connector Functions and Interface Cables Transition Cable Description Pin 1 Location... -
Page 23: Cbr-5011 Connectors
Physical Details CBR-5011 C ONNECTORS USB4 Breakout Board Adapter USB1 USB2 COM1 (Top) USB3 Speaker COM3 COM2 (Bottom) USB4 IDE (Top) PLED (Bottom) Reset = Pin 1 Figure 11. CBR-5011 Connectors CBR-5011 C ONNECTOR UNCTIONS Connector / Function Part Number Description Component IDE and Programmable LEDs... -
Page 24: Jumper Blocks
Physical Details Jumper Blocks UMPERS HIPPED ONFIGURATION 1 2 3 Figure 12. Jumper Block Locations – As Shipped Configuration EPM-14 Reference Manual... -
Page 25: Jumper Summary
Video BIOS Selector In – Primary Video BIOS selected Out – Secondary Video BIOS selected The secondary video BIOS is field-upgradeable using the BIOS upgrade utility. See www.versalogic.com/private/cougarsupport.asp for more information. COM3 RS-422/485 Termination In – 100 Ohm Termination Active Out –... -
Page 26: System Features
Power Input Ground +5VDC Power Input Figure 13 shows the VersaLogic standard pin numbering for this type of 10-pin power connector and the corresponding mating connector. Some manufacturers include a pin-1 indicator that corresponds to pin-10 of the power connector pinout... -
Page 27: Power Requirements
The EPM-14 has one soldered-on DDR memory module with the following characteristics: Size 256 MB Voltage 2.6V Type PC2700 compatible (DDR 333 MHz) CMOS settings default to DDR 333 MHz. Settings to DDR 400 MHz are available, Note but VersaLogic only guarantees operation at the default settings. EPM-14 Reference Manual... -
Page 28: Cmos Ram
System Features CMOS RAM CMOS RAM LEARING A jumper may be installed into V1[2-3] to erase the contents of the CMOS RAM and the real- time clock. When clearing CMOS RAM: 1) Power off the EPM-14. 2) Remove the jumper from V1[1-2], install it on V1[2-3] and leave it for four seconds. -
Page 29: Real Time Clock
System Features Real Time Clock The EPM-14 features a battery-backed 146818-compatible real-time clock/calendar chip. Under normal battery conditions, the clock maintains accurate timekeeping functions when the board is powered off. ETTING THE LOCK The CMOS Setup utility (accessed by pressing the Delete key during a system boot) can be used to set the time/date of the real-time clock. -
Page 30: Interfaces And Connectors
I/O connector J7. A breakout cables and board combination, CBR-5011, is available from VersaLogic that provides discrete connectors for each of the interfaces; however, you may wish to create a custom cable that surfaces only the interfaces required by your application. -
Page 31: Ide
Interfaces and Connectors One IDE interface is available to connect up to two IDE devices, such as hard disks and CD- ROM drives. If the on-board CompactFlash is configured for use, only one other IDE device can be attached to the IDE controller. Connector J8 provides the interface to the IDE controller. Jumper V2[1-2] determines if the CompactFlash plugged into J5 is the master device or slave. -
Page 32: Serial Ports
ONNECTORS See the Connector Location Diagrams on pages 15 for connector and cable information. The pinouts of the DB9M connectors apply to the serial connectors on the VersaLogic breakout board CBR-5011. These connectors use IEC 61000-4-2-rated TVS components to help protect against ESD damage. -
Page 33: Com3 Rs-422/485 Line Driver Control
Interfaces and Connectors COM3 RS-422/485 L RIVER ONTROL The COM3 line driver is controlled by manipulating the RS422/485 Transmit/Receive Control Register (1D3h). RS-485 support is provided but limited to manual flow control. COM3 is set to RS-485 receive mode when COM 3 Mode is set to RS485 ManuFC in CMOS. To enable RS-485 transmit mode, set bit D2. -
Page 34: Usb
Interfaces and Connectors The USB interface on the EPM-14 is OHCI (Open Host Controller Interface) and EHCI (Enhance Host Controller Interface) compatible, which provides a common industry software/hardware interface. The EHCI controller is still available for use by the operating system when the “Usb20” feature is disabled, but booting from USB 2.0 devices or using them in a DOS environment may be slower. -
Page 35: Compactflash
IDE interface. The CF interface supports operation in DMA mode. The following CF modules have been tested and qualified as bootable devices by VersaLogic. Part numbers with a suffix of -3500 are RoHS-compliant. -
Page 36: Programmable Led
Interfaces and Connectors Programmable LED Connector J7 includes an output signal for attaching a software controlled LED. Connect the cathode of the LED to J7, pin 44; connect the anode to +5V. An on-board resistor limits the current to 15 mA when the circuit is turned on. A programmable LED is provided on the CBR-5011 breakout board. -
Page 37: Video Interface
Interfaces and Connectors Video Interface An on-board video controller integrated into the chipset provides high performance video output for the EPM-14. ONFIGURATION The video interface uses PCI interrupt INTA*. CMOS Setup is used to select the IRQ line routed to INTA*. The EPM-14 uses shared memory architecture. -
Page 38: Lvds Flat Panel Display Connector
CMOS Setup provides several options for standard LVDS flat panel types. If these options do not match the requirements of the panel you are attempting to use, contact Support@VersaLogic.com for a custom video BIOS. The 3.3V power provided to pins 19 and 20 of J9 is protected by a 1 amp fuse. -
Page 39: Compatible Lvds Panel Displays
Interfaces and Connectors LVDS P OMPATIBLE ANEL ISPLAYS The following flat panel displays are reported to work properly with the integrated graphics video controller chip used on the EPM-14. Table 14: Compatible Flat Panel Displays Panel Panel Manufacturer Model Number Size Resolution Interface... -
Page 40: Ethernet Interface
The EPM-14 features two Intel 82551ER Fast Ethernet controllers on-board. While these controllers are not NE2000-compatible, they are widely supported. Drivers are readily available to support a variety of operating systems. See VersaLogic website for latest OS support. BIOS C... -
Page 41: Cpu Temperature Monitor
Interfaces and Connectors CPU Temperature Monitor A thermometer circuit constantly monitors the die temperature of the CPU. This circuit can be used to detect over-temperature conditions which can result from fan or heat sink failure or excessive ambient temperatures. The system can be configured to generate an interrupt when the temperature exceeds the BIOS programmed threshold. -
Page 42: System Resources And Maps
System Resources and Maps Memory Map The lower 1 MB memory map of the EPM-14 is arranged as shown in the following table. Various blocks of memory space between C0000h and FFFFFh can be shadowed. CMOS Setup is used to enable or disable this feature. Table 16: Memory Map Start Address End Address... -
Page 43: Interrupt Configuration
System Resources and Maps Interrupt Configuration The EPM-14 has the standard complement of PC type interrupts. Four non-shared interrupts are routed to the PC/104 bus, and up to four IRQ lines can be allocated as needed to PCI devices. The following tables show the default and allowed interrupt settings. -
Page 44: Special Registers
Special Registers Special Control Register SCR (Read/Write) 1D0h PLED Reserved Reserved Reserved Reserved Reserved Reserved Reserved Table 20: Special Control Register Bit Assignments Mnemonic Description PLED Light Emitting Diode – Controls the programmable LED on connector J7. 0 = Turns LED off 1 = Turns LED on D6-D0 –... -
Page 45: Jumper And Status Register
Special Registers Jumper and Status Register JSR (Read-only) 1D2h Reserved Reserved Reserved Reserved Reserved VB_SEL Reserved Table 22: Jumper and Status Register Bit Assignments Mnemonic Description D7-D3 – Reserved – These bits have no function. General Purpose Input – Indicates the status of V2[3-4]. This bit is read-only. 0 = Jumper out 1 = Jumper in VB_SEL... -
Page 46: Appendix A - References
Super I/O SMSC (http://www.smsc.com) SMSC LPC47N217 PC/104 Specification PC/104 Consortium (www.controlled.com/pc104) PC/104 Resource Guide (www.versalogic.com) PC/104-Plus Specification VersaLogic Corporation PC/104 Resource Guide General PC Documentation Microsoft Press (www.microsoft.com/learning/books) The Programmer’s PC Sourcebook General PC Documentation Powell’s Books (www.powells.com) The Undocumented PC...
