3. Installation

1. Plug fiber into T location labeled on the Transmitter unit. Plug that corresponding end of fiber into
R location labeled on the Receiver unit.
2. Plug fiber into R location labeled on the Transmitter unit. Plug that corresponding end of fiber
into T location labeled on the Receiver unit.
3. Connect the power supply to the Receiver and plug corresponding end into a suitable AC power
source.
4. Connect your PC to one of the Firewire locations
a. Connect your local Firewire device
(Firewire Connector) labeled on the Transmitter unit.
5. Connect the power supply to the Transmitter and plug corresponding end into a suitable AC
power source (OPTIONAL, depending on your power consumption)
6. Connect your devices(s) into the device port(s) (
Note: Please allow up to one minute for the CPU to recognize the Firewire system.
Your Firewire 800 Extender System is now properly connected.
MAN-000012
on the Transmitter unit.
(if applicable) to the other Cable Link location
Firewire Connectors) on the Receiver unit.
23 REVISION G
