- Page 1 USB and 1394b EXTENDER USB Models 1.1 and 2.0 Firewire Model 800 Product Manual Thinklogical™ Inc. 100 Washington Street Milford, Connecticut 06460 U.S.A. Telephone (203) 647-8700 Fax (203) 783-9949 www.thinklogical.com MAN-000012 REVISION G...
-
Page 2: Copyright Notice
Copyright Notice Copyright © 2008 All rights reserved. Printed in the U.S.A. Thinklogical™, a subsidiary of Logical Solutions, Incorporated 100 Washington Street Milford, Connecticut 06460 U.S.A. Telephone (203) 647-8700 All trademarks and service marks are property of their respective owners. -
Page 3: Table Of Contents
General System Features ......................4 2.2. Technical Specifications ......................4 2.3. Product Overview - USB Extender .................... 5 2.3.1. USB 1.1 Transmitter ......................6 2.3.2. USB 1.1 Receiver ....................... 7 2.3.3. USB 2.0 Transmitter ......................8 2.3.4. USB 2.0 Receiver ....................... 9 2.3.5. - Page 4 Symbols Found on Product ....................25 Safety Standards ........................... 26 Laser Module ..........................26 External Fiber Connector ....................... 26 USB 1.1 and 2.0 Power Supply ...................... 26 Firewire 800 Power Supply ......................26 How to Contact Us ..........................27 Customer Support .......................... 27 1.1.
-
Page 6: Products: Usb Extenders
Products: USB Extenders USB 1.1 Extender USB 2.0 Extender MAN-000012 REVISION G... -
Page 7: Introduction
Product Overview 1.2.1. USB Extender The USB Extender (1.1 and 2.0 Models) is a fiber optic extender designed to extend USB 1.1 or 2.0 interface signals up to 1000 meters (3280 feet) over a standard duplex multimode fiber. With the USB Extender, all high speed USB 1.1 or 2.0 peripherals can be conveniently located while operating at... -
Page 8: Ordering Information
1.3. Ordering Information All models listed are available from Thinklogical™: USB-000001-SCTX USB 1.1 EXTENDER TRANSMITTER, SC USB-000001-SCRX USB 1.1 EXTENDER RECEIVER, SC USB-000001-STTX USB 1.1 EXTENDER TRANSMITTER, ST USB-000001-STRX USB 1.1 EXTENDER RECEIVER, ST USB-000002-SCTX USB 2.0 EXTENDER TRANSMITTER, SC USB-000002-SCRX USB 2.0 EXTENDER RECEIVER, SC... -
Page 9: System Features
2. System Features 2.1. General System Features Extends Hi-Speed USB 1.1 or 2.0 connection up to 1000 meters (3280 feet) Four port Class A device Installation is Plug-and-Play, no adjustments are necessary Supports USB 1.1 low-speed /full-speed and USB 2.0 hi-speed devices... -
Page 10: Product Overview - Usb Extender
2.3. Product Overview - USB Extender MAN-000012 REVISION G... -
Page 11: Usb 1.1 Transmitter
2.3.1. USB 1.1 Transmitter 5VDC POWER LINK HOST MAN-000012 REVISION G... -
Page 12: Usb 1.1 Receiver
2.3.2. USB 1.1 Receiver 5VDC POWER LINK MAN-000012 REVISION G... -
Page 13: Usb 2.0 Transmitter
2.3.3. USB 2.0 Transmitter 5VDC POWER LINK HOST MAN-000012 REVISION G... -
Page 14: Usb 2.0 Receiver
2.3.4. USB 2.0 Receiver 5VDC POWER LINK MAN-000012 REVISION G... -
Page 15: Cables
2.3.5.1. Fiber Optic Cables Fiber Optic cables for the USB Extender system are not included, but are available for purchase. Please contact Thinklogical™ for a quotation on your required cable length. When connecting the fiber optic cables, you must be sure to: ... -
Page 16: Power Supply -Pwr-000022-R (Quantity 2)
2.3.5.3. USB Type B – Transmitter Connect your PC to the location labeled Host on the Transmitter unit using the USB Type A to USB Type B Cable (CBL000015-006FR) that was provided with your USB Extender system. 2.3.6. Power Supply –PWR-000022-R (Quantity 2) ... - Page 17 Separate wall-pack AC/DC adapters (part number PWR-000022-R) are included. A single power jack accepts the 5VDC input. Universal Input: 100 – 240 VAC 50/60Hz Nominal Continuous Short Circuit Protection Over Voltage Protection Conductive EMI Meets CISPR/FCC Class B high efficiency, 75% Typical AC Plug Can Be Changed ...
-
Page 18: Installation
5. Connect your PC to the Host location (USB Type B Connector) labeled on the Transmitter unit. 6. Connect your devices(s) into the device port(s) (USB Type A Connector) labeled 1,2,3,4 on the Receiver unit. Your USB (1.1 or 2.0) Extender System is now properly connected. 3.1. LED Status 3.1.1. -
Page 19: Receiver
3.1.2. Receiver LED Label Status Power LED is ON (solid green) when power supply is properly connected Device Ports labeled LED is ON (solid green) when the device(s) is (are) properly connected 1, 2, 3, 4 and once the unit enumerates Link Shows the status of the connection LED is ON (solid green) when the Power, device port(s), and Fiber are... -
Page 20: Product: Firewire 800 Extender
Product: Firewire 800 Extender MAN-000012 REVISION G... -
Page 21: Introduction
1. Introduction 1.1. Contents 1.1.1. Firewire (1394b) When you receive your Thinklogical™ 1394b Extender, you should find the following items: 1394b Extender – Transmitter 1394b Extender – Receiver AC Power Supply (PWR-000033-R) – Quantity 2 AC Power Cord (PWR-000008-R) – Quantity 2 1394 Bilingual to 6 Pin 1394, 6 Feet (CBL000100-006FR) –... -
Page 22: System Features
(1) 2.0mm power connector Optical Cable Duplex Fiber, multi-mode, 50 micron or 62.5 micron. (Fiber Cable is either customer-supplied or can be ordered from Thinklogical.) Operating Temperature and 0 to 50 °C (32 to 122 °F); 10 to 95% RH, non-condensing... -
Page 23: Product Overview - Firewire 800 Extender
2.3. Product Overview – Firewire 800 Extender MAN-000012 REVISION G... -
Page 24: Firewire 800 Transmitter
2.3.1. Firewire 800 Transmitter 12V DC POWER LINK The Future of Access and Control Firewire Extender IEEE-1394b Fiber Optic Extension System Model Firewire 800 Transmitter CABLE CABLE POWER POWER MAN-000012 REVISION G... -
Page 25: Firewire 800 Receiver
2.3.2. Firewire 800 Receiver 12V DC POWER LINK The Future of Access and Control Firewire Extender IEEE-1394b Fiber Optic Extension System Model Firewire 800 Receiver CABLE CABLE POWER POWER MAN-000012 REVISION G... -
Page 26: Cables
2.3.3. Cables 2.3.3.1. Fiber Optic Cables When connecting the fiber optic cables, you must be sure to: Connect the fiber connector labeled „T‟ on the Transmitter to the fiber connector labeled „R‟ on the Receiver. Connect the fiber connector labeled „R‟ on the Transmitter to the fiber connector labeled „T‟... -
Page 27: Power Supply - Pwr-000033-R (Quantity 2)
2.3.4. Power Supply – PWR-000033-R (Quantity 2) Universal Input: 90 – 264 VAC Continuous Short Circuit Protection Meets EN55022 Class “B”, Conducted High Efficiency, 85% Typical MAN-000012 REVISION G... -
Page 28: Installation
3. Installation 1. Plug fiber into T location labeled on the Transmitter unit. Plug that corresponding end of fiber into R location labeled on the Receiver unit. 2. Plug fiber into R location labeled on the Transmitter unit. Plug that corresponding end of fiber into T location labeled on the Receiver unit. -
Page 29: Led Status
3.1. LED Status 3.1.1. Transmitter LED Label Status Power LED is ON (solid green) when power supply is properly connected and sufficient power is provided. LED is OFF when power consumption is too high and the supplied power supply is necessary. -
Page 30: Product Identification
Product Identification 1. Markings 1.1. Product Serial Number The USB and FIREWIRE EXTENDER products have a unique serial number, imprinted on a small silver label that is placed on the bottom of the chassis. The serial number includes a date-code. The format for the date-code is two digits for the month;... -
Page 31: Safety Standards
Electrical Safety per EN60950 Certified by TUV and CSA 2. External Fiber Connector Flammability Rating UL94V0 3. USB 1.1 and 2.0 Power Supply Thinklogical™ Part Number: PWR-000022-R UL File Number: E176177 4. Firewire 800 Power Supply Thinklogical™ Part Number: PWR-000033-R... -
Page 32: How To Contact Us
Thank you to our customers for choosing a Thinklogical™ product for your application. We appreciate your business and are interested in helping you successfully use our product. Thinklogical™ is here to help you. To contact Thinklogical™, use the following telephone numbers and internet-based methods. -
Page 33: Telephone
1.3. Telephone Telephone Sales: Contact our expert technically oriented sales staff via telephone in Milford, CT at (203) 647-8700 or if in the continental US, you may use our toll-free number (800) 291-3211. We are here Monday through Friday from 9:00am to 5:00pm, Eastern Time Zone. Ask for their direct dial phone number when you call. -
Page 34: Product Support
(ii) modifications to or repairs of the product that are made by any party other than Thinklogical or a party acting on Thinklogical‟s behalf, or (iii) combination of the product with third party products that is not consented to by Thinklogical. -
Page 35: Our Address
USB or FIREWIRE EXTENDER system, please call us at (203) 647-8700 and let us help. If shipping something with an RA # or if you‟d like to write us, we are located at: Thinklogical™ Inc. 100 Washington Street Milford, CT 06460 USA... -
Page 36: Appendix A - Dimensions
Appendix A - Dimensions 1. USB 1.1 and 2.0 Transmitter 6.61" (167.89mm) 5 VDC POWER LINK 1.09" (27.61mm) .25" (6.35mm) .50" Dia. (4X) (12.70mm) .25" (6.35mm) (4X) The Future of Access and Control 4.0" USB EXTENDER (101.60mm) 3.0" (76.25mm) USB 2.0 Hi-Speed Extension System... -
Page 37: Usb 1.1 And 2.0 Receiver
2. USB 1.1 and 2.0 Receiver 6.61" (167.89mm) 5VDC POWER LINK 1.09" (27.61mm) .25" (6.35mm) .50" Dia. (4X) (12.70mm) .25" (6.35mm) (4X) The Future of Access and Control 4.0" USB EXTENDER (101.60mm) 3.0" 4.0" (76.25mm) 3.0" USB 2.0 Hi-Speed Extension System... -
Page 38: Firewire 800 Transmitter
3. Firewire 800 Transmitter 6.61" (167.89mm) 12V DC POWER LINK 1.09" (27.61mm) .25" (6.35mm) Dia. (4X) .50" .25" (6.35mm) (4X) (12.70mm) The Future of Access and Control 4.0" Firewire Extender (101.60mm) 3.0" (76.25mm) IEEE-1394b Fiber Optic Extension System Model Firewire 800 Transmitter 6.11"... -
Page 39: Firewire 800 Receiver
4. Firewire 800 Receiver 6.61" (167.89mm) 12V DC POWER LINK 1.09" (27.61mm) .25" (6.35mm) Dia. (4X) .50" .25" (6.35mm) (4X) (12.70mm) The Future of Access and Control 4.0" Firewire Extender (101.60mm) 3.0" (76.25mm) IEEE-1394b Fiber Optic Extension System Model Firewire 800 Receiver 6.11"... - Page 40 For Your Notes: MAN-000012 REVISION G...
