Appendix A - Dimensions

1. USB 1.1 and 2.0 Transmitter

6.61" (167.89mm)
5 VDC
POWER LINK
T R
1.09" (27.61mm)
.25" (6.35mm)
.50"
Dia. (4X)
(12.70mm) .25" (6.35mm) (4X)
2.0
The Future of Access and Control
4.0"
USB EXTENDER
(101.60mm)
3.0"
(76.25mm)
USB 2.0 Hi-Speed Extension System
Model USB-2
Transmitter
6.11" (155.19mm)
5.61" (142.49mm)
HOST
Tolerance: ± 0.039" (1mm)
