3.1.

LED Status

3.1.1. Transmitter

LED Label
Power
Link
Cable Power

3.1.2. Receiver

LED Label
Power
Link
Cable Power
MAN-000012
Status
LED is ON (solid green) when power supply is properly connected and
sufficient power is provided.
LED is OFF when power consumption is too high and the supplied power
supply is necessary.
Shows the status of the connection.
LED is ON (solid green) when fiber are properly connected.
LED is ON (solid green) when enough power is supplied.
LED is OFF when power consumption is too high and the supplied power
supply is necessary.
Status
LED is ON (solid green) when power supply is properly connected and
sufficient power is provided.
Shows the status of the connection.
LED is ON (solid green) when fiber are properly connected.
LED is ON (solid green) when power is properly connected.
24 REVISION G
