- Page 1 SDIXtreme Product Manual For all Products Thinklogical® LLC 100 Washington Street Milford, Connecticut 06460 U.S.A. Telephone 203-647-8700 Fax 203-783-9949 Revision E July 2012...
- Page 2 Copyright © 2012. All rights reserved. Printed in the U.S.A. Thinklogical® LLC 100 Washington Street Milford, Connecticut 06460 U.S.A. Telephone 203-647-8700 All trademarks and service marks are property of their respective owners. Subject: SDIXtreme 3G and 3G+ Revision: E, July 2012 Revision E July 2012...
-
Page 3: Table Of Contents
Contents ........................... 9 Dry Contact Alarm (3G+ Rack-Mount) ...................10 Hot Swappable Power Supplies (3G+ Rack-Mount) ..............11 Fiber Optic Cable ........................11 Connecting to the Thinklogical® SDI Xtreme 3G ..............12 Installation ..........................12 Set-Up ...........................12 Order of Installation Events ...................12 RS422 Pin-outs (3G+) ....................12 Part 2: SAFETY REQUIREMENTS ..................13... - Page 4 Product Support ........................18 Warranty ........................18 Our Address ........................19 APPENDIX A: ORDERING INFORMATION ................20 APPENDIX B: QUICK START GUIDES ...................26 Revision E July 2012...
-
Page 5: Preface
Part 2 – Safety Requirements: Thinklogical® strongly recommends that you read this section of the manual prior to starting the hardware assembly. Part 3 – Product Support: Thinklogical® provides the best customer support available. If you have any questions or need to contact us, please refer to this section of the manual. -
Page 6: Introduction
Introduction The Logical Solution The SDI Xtreme 3G and 3G+ product series is available with LC-type fiber connectors. See Appendix A, for ordering details on the complete line of the Thinklogical SDI Xtreme 3G and 3G+ products. Theory of Operation The SDI Xtreme 3G and 3G+ product series is a compact, broadcast quality SDI over fiber extension system. -
Page 7: Technical Specifications
Technical Specifications Indicators: (3) Power, Data Rate SD, HD, 3G – Lock Detect - Active Dimensions: 3G = 4.96 x 2.25 x 1.03 (in) – 125.98 x 57.12 x 26.14 (mm) 3G+ = Height: 1.68” (4.3cm) Depth: 3.427” (8.7cm) Width: 5.609” (14.25 cm) 3G+ RM = Rack Size: EIA 19"... - Page 8 OPTICAL Output: Connector LC receptacle Fiber Type Multi-mode 10 km Single Mode 40 km Single Mode Wavelength (nominal) 850nm 1310nm 1550 nm Emitter Type VCSEL DFB Laser DFB Laser Output Power (nominal) -4dBm -1.5dBm 2.5dBm Re-clocking At 270 Mbps, 1.485 Gbps & 2.97 Gbps RECEIVER Specifications: Fiber Input Connector...
-
Page 9: Part 1: Hardware
Part 1: Hardware Contents When you receive your Thinklogical® SDI Xtreme 3G, you should receive the following items: SDI Xtreme 3G Hardware • 5VDC Power Cords – PWR-000022-R (3G, 3G+) • AC power cord, PWR-000006-R (International connections may differ) – Qty 2 (3G+ Rack- •... -
Page 10: Dry Contact Alarm (3G+ Rack-Mount)
Dry Contact Alarm (3G+ RM Only) There are dry contact alarms located on each module in the 3G+ Rack Mount units. When there is an alarm condition, such as an over temperature condition or an issue with a power supply or fan, the relay is energized. -
Page 11: Hot Swappable Power Supplies (3G+ Rack-Mount)
To hot swap a power supply, simply unscrew the failed module and replace it with a new power supply module (part number VTM-000001, which can be ordered from Thinklogical™). Figure 6: Power Supply Status and Rocker Switch Location Fiber Optic Cable Fiber optic cable must run between the Transmitter unit and the Receiver unit. -
Page 12: Connecting To The Thinklogical® Sdi Xtreme 3G
Connecting to the Thinklogical® SDI Xtreme 3G Installation All physical connections to the product use industry-standard connectors. Non-supplied cables that may be needed are commercially available. All connections are found on the rear of the unit. Set-Up Note: To avoid inadvertent exposure to the lasers, the fiber optic cables should be attached to the SDI Xtreme 3G prior to powering up the units. -
Page 13: Part 2: Safety Requirements
Regulatory Compliance ® Thinklogical products are designed and made in the U.S.A. Products have been tested by a nationally recognized testing laboratory and found to be compliant with the following standards (both domestic USA and many international locations). -
Page 14: European Union
European Union Declaration of Conformity ® Manufacturer’s Name & Address: Thinklogical 100 Washington Street Milford, Connecticut 06460 USA Telephone (203) 647-8700 Product Name Model: SDI Xtreme 3G These products comply with the requirements of the Low Voltage Directive 72/23/EEC and the EMC Directive 89/336/EEC. -
Page 15: Supplementary Information
Supplementary Information The following statements may be appropriate for certain geographical regions and might not apply to your location. This Class A digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations. Cet appareil numérique de la classe A respecte toutes les exigencies du Règlement sur le mat érial brouilleur du Canada. -
Page 16: Product Serial Number
Product Serial Number Thinklogical® products have a unique serial number, imprinted on an adhesive label that is fixed to the bottom of the chassis. The serial number includes a date-code. The format for the date-code is 2 digits for the month, 2 digits for the day and 2 digits for the year, plus two or three digits for a unique unit number. -
Page 17: Part 3: Thinklogical® Support
Part 3: Thinklogical® Support Customer Support Thinklogical® is an engineering company and you will receive the information you require directly from our most knowledgeable engineers. We believe that the first line of support is the design engineer that developed the product. Therefore, your questions will be handled promptly by our in-house engineers who are most familiar with your products. -
Page 18: Telephone
(ii) modifications to or repairs of the product that are made by any party other than Thinklogical or a party acting on Thinklogical’s behalf, or (iii) combination of the product with third party products that is not consented to by Thinklogical. -
Page 19: Our Address
Repairs may be made with refurbished parts. If repair or replacement is not possible, Thinklogical may keep the defective product and refund the amount that you paid for the defective product. These are Thinklogical’s sole obligations, and your exclusive remedies, for a breach of the limited warranty set forth above. -
Page 20: Appendix A: Ordering Information
Appendix A: Ordering Information Thinklogical's SDI Xtreme Optics for 3G, 3G+, 3G+ Rack-mount Part Number Description SDI FIBER OPTIC EXTENDER OPTICS OPTIONS for SINGLE MODE VOP-S19 SDI Xtreme 3G Optics Option, Single Mode 4km, 1 SFP Dual Fiber, LC VOP-S20... - Page 21 Revision E July 2012...
- Page 22 Revision E July 2012...
- Page 23 Revision E July 2012...
- Page 24 Revision E July 2012...
- Page 25 Revision E July 2012...
-
Page 26: Appendix B: Quick Start Guides
Appendix B: Quick Start Guides Revision E July 2012... - Page 27 Revision E July 2012...
- Page 28 Revision E July 2012...
- Page 29 Revision E July 2012...
