- Page 1 Velocitykvm T-Series High Reliability, Rack-Space Saving, Video and Audio Extension Solutions T-4200 SDI Modules KVM Extension Solution PRODUCT MANUAL Thinklogical LLC 100 Washington Street Milford, Connecticut 06460 U.S.A. Telephone: 1-203-647-8700 Fax: 1-203-783-9949 www.thinklogical.com ® Extend Distribute Innovate...
- Page 2 Extend Distribute Innovate Copyright Notice Copyright © 2011. All rights reserved. Printed in the U.S.A. Thinklogical LLC 100 Washington Street Milford, Connecticut 06460 U.S.A. Telephone: 1-203-647-8700 All trademarks and service marks are property of their respective owners. Subject: VelocityKVM T-Series SDI Modules Product Manual Revision: A, September 2011 T-Series SDI Modules, Rev.
-
Page 3: Table Of Contents
Thinklogical’s VelocityKVM T-Series SDI Extender Modules ................... 4 SDI Module Features ..............................5 1. SYSTEM FEATURES ..............................6 1.1 T-4200 Series SDI and DVI Module Features ....................6 1.2 Contents: SDI Extender Modules ........................7 1.2.1 Video Cables ............................. 7 1.2.2 Peripheral cables ............................ -
Page 4: Preface
Extend SDI and RS-422 signals up to 40 Kilometers T-Series SDI Modules are an interface option designed for use in the VelocityKVM T-4200 Modular Chassis (sold separately). These modules enable users to transmit up to four SD/HD signals, or up to two 3G SDI signals, with or without embedded audio and data. -
Page 5: Sdi Module Features
® SDI Module Features The reliability of T-Series SDI Modules stem from the quality of its design and construction, featuring advanced, integrated re-clocking circuitry designed into the transmitter and receiver. In addition, equalized and re-driven SDI loop-through is provided on the transmitter. These key features provide assurance that the signal is equalized and re-clocked prior to fiber transmission, thus retaining all of the signal’s initial parameters and allowing for pristine, re-clocked SDI outputs on the receiver. -
Page 6: System Features
The VelocityKVM line of extenders continues to evolve and add value with exciting new capabilities. The VelocityKVM T-4200 Series is housed in a high reliability, rack-space-saving chassis that includes all of the same capabilities in a 1U device that used to require 2U. Featuring a dual interface and current sharing power supplies, each 1U chassis supports two separate interface modules, allowing users to combine module options within one chassis. -
Page 7: Contents: Sdi Extender Modules
Product Quick Start Guide 2. CONNECTING THE T-4200 EXTENDER All physical connections to the T-4200 Extender use industry-standard connectors. Non-supplied cables are commercially available. All connections are found on the rear panel of the unit. 2.1 Transmitter Modules The Transmitter Module connects to the CPU (or other sources) using standard copper cables. The Transmitter then connects to a Receiver via multi-mode or single-mode fiber-optic cables. -
Page 8: Module Leds
® 2.4 Module LEDs The Transmitter, Receiver and Transceiver Modules each feature two pairs of LEDs. Each pair of LEDs functions as follows: SDI Module LEDs: (On Tx, Input signal on BNC when lit. On Rx, Input signal on Fiber when lit.) (Inoperative) (Operating in HD Mode when lit.) (Operating in SD Mode when lit.) -
Page 9: Rear Panel Views
STM Modules in Transmitter, Receiver and Transceiver Configurations 2.6.2 T-4200 Chassis SDI Module Options STM-L1L1X2-LCTX T-4200 SDI Dual Transmitter Module: 2 Inputs (with 2 Loop Outs) & 2 SFPs STM-C1C1X2-LCRX T-4200 SDI Dual Receiver Module: 2 SFPs & 2 Pairs of SDI Outputs STM-L1C1X2-LCTR T-4200 SDI Transceiver Module, TX: 1 Input with Loop Out &... -
Page 10: Firmware Upgrades
Transmitter Module, extending both SDI and DVI video signals, along with peripheral signals, up to 40 km. A VelocityKVM T-4200 Chassis, equipped with one STM and one VTM-4 Receiver Modules, is located at the destination, extending two SDI and two DVI displays/peripherals to four workstations. -
Page 11: Four Sdi Video Sources/Stm Transceivers
® 2.8.2 Four SDI Video Sources, of which two each are connected to a T-4200 Chassis housing two STM Transceiver Modules, extending video and peripheral signals, via eight fiber optic cables, to another T-4200 Chassis equipped with two more STM Transceiver Modules. Each STM TR extends one SDI video IN signal to two SDI video OUT ports. -
Page 12: Technical Specifications
® 2.9 Technical Specifications Each Thinklogical VelocityKVM T-Series Module is designed to the following specifications: Transmitter: Video BNC (2) Serial Port DB9 Female Fiber Connectors Alarm Form C (3 contact) Copper Connectors Receiver: Video BNC (2) Serial Port DB9 Male... -
Page 13: Regulatory & Safety Compliance
3.1.2 Regulatory Compliance Thinklogical VelocityKVM Extender products are designed and made in the U.S.A. VelocityKVM Extender products have been tested by a certified testing laboratory and found to be fully compliant with... -
Page 14: Supplementary Information
EN61000-4-6: 1996 Conducted Immunity Test EN61000-4-8: 1993 Magnetic Field Test EN61000-4-11: 1994 Voltage Dips & Interrupts Test Class 1 LASER All T-4200 modules are designed and identified as products CLASS 1 LASERS do not require any special precautions under conditions of normal use. -
Page 15: Product Serial Number
To contact us, please use the following telephone numbers and internet-based methods: Thinklogical is an engineering company and you will receive the information you require directly from our most knowledgeable engineers. We believe that the first lines of support are the design engineers that developed each product. -
Page 16: Website
Email Thinklogical is staffed Monday through Friday from 8:30am to 5:00pm, Eastern Time Zone. We will make every effort to respond to your email inquiries promptly. Please use the following email addresses for any of your concerns: info@thinklogical.com –... -
Page 17: Warranty
If you wish to return your device, contact the Thinklogical authorized dealer where you purchased the device, or if you purchased directly, call Thinklogical at 1-800-291-3211 (USA). -
Page 18: Appendix A: Quick Start Guide: Stm-24 Transmitters To Stm-24 Receivers (Direct)
® Appendix A- Quick Start Guide: STM-24 Transmitters to STM-24 Receivers T-Series SDI Modules, Rev. A September 2011... -
Page 19: Appendix B: Thinklogical Kvm Extenders- Theory Of Operation
® Appendix B- Thinklogical KVM Extenders The Logical Solution VelocityKVM Extension Systems are designed for high performance visual applications that require DVI, SDI or RGB video as well as peripheral support (VelocityKVM-5 supports DVI or RGB). The system allows users, via optical fiber, to station and operate a digital monitor(s) and peripherals from just a few meters away to up to 40 kilometers away from the controlling computer, securely and without loss of resolution. -
Page 20: Appendix C: Velocitykvm T-Series Ordering Information
SDI MODULES Velocity T-Series SDI Modules STM-C1C1X2-LCRX SDIXtreme 3G+ T-4200 Dual Receiver Module with 2 SFPs and 2 Pairs of SDI Outputs, LC STM-L1C1X2-LCTR SDIXtreme 3G+ T-4200 Transceiver Module: TX: 1 Input with Loop-out and 1 SFP, LC RX: 2 SDI Outputs and 1 SFP, LC...
