Firewire 800 Receiver - Thinklogical 1.1 Product Manual

4. Firewire 800 Receiver

1.09"
(27.61mm)
.50"
(12.70mm)
4.0"
(101.60mm)
3.0"
(76.25mm)
MAN-000012
12V DC
POWER LINK
T
.25" (6.35mm) (4X)
800
The Future of Access and Control
Firewire Extender
IEEE-1394b Fiber Optic Extension System
Model Firewire 800
Tolerance: ± 0.039" (1mm)
6.61" (167.89mm)
R
Receiver
6.11" (155.19mm)
5.61" (142.49mm)
CABLE CABLE
POWER POWER
34
.25" (6.35mm)
Dia. (4X)
REVISION G
