ICS-480V 4U Industrial Workstation with 8.4" LCD and 14 slots
2.1 System Installation
WARNING: Before starting the installation process, be
2.1.1 Removing the top cover
First, remove the chassis cover. The top cover is fixed
to the chassis by four screws.
1. Release four screws on the sliding rail of both
sides.
2. Lift the cover.
System Setup
sure to shut down all power from the
chassis. Do this by turning off the power
switch, and unplugging the power cord
from the power outlet. When in doubt,
consult with an experienced technician.
Figure 2.1: Top Cover
backplane User's Manual
Chapter 2
System Setup
5
