Comtech EF Data CSAT-5060 Installation And Operation Manual page 94

C-Band Transceiver
CSAT-5060 5 to 25 Watt Installation
Item No.
1
2
3
4
5
6
Part No.
FP/BR0095
HW/M8X1.25MMHEX
HW/M81.25X20MMFHSS
HW/M8FLATSS
HW.M8SPRINGNUT
HW/M8LOCKSS
Figure A-2. Single-Thread Bracket, AS/0608
Nomenclature
Bracket, Single-Thread 25W CSAT
Bolt, Hexhead
Screw, Flathead
Washer, Flat SS
Springnut
Washer, Splitlock SS
A–4
Revision 1
MN/CSAT5060.IOM
QTY
1
4
4
4
4
4
