C-Band Transceiver
CSAT-5060 100/125 Watt Installation
2
3
Item No. Part No.
1 FP/WG0034
2 FP/WG0043
3 FP/WG0051
4 GA/GSKTCP137FUL
5 HW/M5FLAT
6 HW/M5LOCK
7 SW/WG3AGSM
8 HW/M5X.08X12MMHEX
1
4
Nomenclature
Waveguide Termination, Small Fins
Waveguide CPRG137, 90° "E" 5.50 Flex x 2.00
Waveguide, CPRG137, "Jogged"
Gasket, CP137, Full Thick
Washer, M5 Flat
Lockwasher, M5 SS, Metric
Switch, CPR137G, +24V, Sealed Metric
Bolt, M5X.08X12MM Hexhead SS
. Waveguide Switch, TX 1:1, AS/0478
Figure C-11
5
6
8
C–13
Revision 1
MN/CSAT5060.IOM
