Comtech EF Data CSAT-5060 Installation And Operation Manual page 107

C-Band Transceiver
CSAT-5060 5 to 25 Watt Installation
Item Part No.
1 SW/COAX-N-F-Sealed
2 RF/WG9605
3 HW/M4X.07X8MMPHMS
4 HW/M4LOCK
Nomenclature
Switch COAX N-FE
Attenator, Modification
Screw, Panhead
Washer, Lock
Figure A-18. TX/Remote Switch Assembly, AS/0503
A–17
Revision 1
MN/CSAT5060.IOM
QTY
1
1
4
4
