C-Band Transceiver
CSAT-5060 100/125 Watt Installation
Item
Part No.
1
CA/RF0097
2
CA/WR0051
3
CA/WR0052
4
CA/WR0053
5
CA/WR0053
Nomenclature
Cable, Output RF
Cable, Control-LNA Switch
Cable, Control-TX Switch
Cable, Communication
Cable, Communication
Figure C-9
. Cable Kit
C–11
Revision 1
MN/CSAT5060.IOM
QTY
4
1
1
1
1
