Cable Installation - Comtech EF Data CSAT-5060 Installation And Operation Manual

C-Band Transceiver
CSAT-5060 5 to 25 Watt Installation
A.5.1

Cable Installation

Refer to Figure A-24.
Care should be exercised in cable installation. Install the cables using the most direct route
and secure with clamps and ties. Avoid all sharp bends.
Cable connectors used in outdoors application must be sealed to avoid leakage,
particularly, N-type connectors. Moisture can seep into junctions at the plug end of the
connector, between the fixed and movable parts, and where the cable connects to the
connector. Signal attenuation and possible loss of signal can occur in the presence of
moisture. All cable junctions must be sealed with a self-amalgamating tape, such as 3M,
Type 23 Scotch Self-Amalgamating tape, or equivalent, including military style (MS)
connectors.
A–22
Revision 1
MN/CSAT5060.IOM
