Redundancy Configuration; Mounting Kit - Comtech EF Data CSAT-5060 Installation And Operation Manual

C-Band Transceiver
CSAT-5060 100/125 Watt Installation
C.5 R
EDUNDANCY
C.5.1

Mounting Kit

Part No.
AS/0438
AS/0460
AS/0461
AS/0478
AS/0490
AS/TBD
Part No.
*AS/0414
*AS/0415
AS/0479
*Refer to Single Thread Configuration.
C
ONFIGURATION
Table C-2. Final 1:1, C-Band Assembly
Nomenclature
Kit, LNA Mounting
Kit, Waveguide CPR137G
Kit, Waveguide CPR229
Switch, Waveguide, TX 1:1
Assy, Remote Switch Box
Cable Kit (See Fig. 2-12)
Table C-3. 1:1 Mounting Assembly, AS/0598
Nomenclature
Redundancy Kit, Pole Mount
Single-Thread Mounting Kit
Switch, Mount Kit TX
C–9
Revision 1
MN/CSAT5060.IOM
QTY
1
1
1
1
1
1
QTY
2
2
1
