Comtech EF Data CSAT-5060 Installation And Operation Manual page 117

C-Band Transceiver
CSAT-5060 50 Watt Installation
Item No. Part No.
1 FP/BR0078
2 FP/BR0072
3 FP/BR0070
4 FP/BR0071
5 FP/BR0069
6 HW/M8X1.25X25HEXSS
7 HW/M8FLATSS
8 HW/M8LOCKSS
9 HW/M8SPRINGNUT
10 HW/M8X1.25MMHEXNUTSS
11 HW/BLK-PIPE2-8
Nomenclature
Bracket, Unistrut
Bracket, Strap Tensioner
Bracket, Strap-Termination Pole Mounting Kit
Bracket, 1 1/4 Strap
Bracket, Strap-Fixed, Pole Mounting Kit
Bolt, Hexhead, M8X1.25X25, SS
Washer, Flat, M8 SS, Metric
Washer, Split lock, M8, SS, Metric
Springnut, M8 xX 1.25
Nut, Hex M8X1.25X16MM, SS
Pipe, Block
Figure B-1. Universal Pole Mounting Kit, AS/0414
B–3
Revision 1
MN/CSAT5060.IOM
QTY
1
1
1
1
1
2
7
7
2
5
2
