C-Band Transceiver
CSAT-5060 5 to 25 Watt Installation
A.2

Single-Thread Configuration

WARNING
A.2.1

Mounting Kit

The following mounting is providing to pole-mount the unit in a single-thread
configuration. The following tables reflect the contents of the mounting kits.
The Downconverter RF input connector is wired to supply DC voltage to an
LNA. This voltage is capable of damaging any test equipment connected to
the connector. Do not connect test equipment to this connector without a
coaxial DC block between the connector and the test equipment.

Table A-1. Universal Pole Mount, AS/0599

Part No. Nomenclature
AS/0414 Kit, Universal Pole Mount
AS/0608 Bracket, Mount 25W Single Thread
A–2
Revision 1
MN/CSAT5060.IOM
QTY
1
1
