CSAT-5060 C-Band Transciever
+10 dBm Model C-Band Transceiver
9.1.1

Function Description

The Transceiver is designed for use in communication systems, or in satellite uplink data
systems, for the reception of SCPC, DAMA, and TDMA communication signals. It also
can be used in communications system applications with full transponder HDTV and
analog TV. The RF operating frequency range is as follows:
This transceiver provides an upconverted ouput used to drive an external SSPA or
TWTA. The down conversion side of the transceiver operates the same as the higher
power versions of the same CSAT. The converter is environmentally sealed and is
designed to be hard mounted on or near the antenna structure.
CAUTION

9.1.2 Prime Power Level

The power input requirements for the C-band Downconverter is as follows:
Prime Power Level
Current Requirements

9.1.3 Physical Dimensions

Upconverter section
Downconverter section
The downconverter RF input connector is wired to supply DC voltage to an
LNA. This voltage is capable of damaging any test equipment connected to
the connector. Do not connect test equipment to the connector without a
coaxial DC block between the connector and the test equipment.
100 to 125 Volts AC, or 205 to 240 Volts AC, 47 to 623 Hz.
Typical current requirements is 1.2 amps at 100 to 125 VAC or
0.6 amps at 205 to 240 VAC.
Parameter
Length 11 inches
Width 8 inches
Height 8 inches
Weight 36 pounds
As ordered
As ordered
Specification
(28 cm)
(20 cm)
(20 cm)
(16 kg)
9–2
Revision 1
MN/CSAT5060.IOM
