Redundancy Configuration; Mounting Kit - Comtech EF Data CSAT-5060 Installation And Operation Manual

C-Band Transceiver
CSAT-5060 5 to 25 Watt Installation
A.4

Redundancy Configuration

A.1.1
A.1.2
A.4.1

Mounting Kit

Table A-3 and Table A-4 reflects the contents of the mounting kits.
IMPORTANT
Table A-4. Assembly, 1:1 25W CSAT Switching, AS/0510
Part No.
AS/0438
AS/0440
AS/0461
AS/0490
AS/0503
Note: Refer to Chapter 2, LNA for details.
Table A-3. 1:1 Mounting Kit Assembly, AS/0596
Part No.
*AS/0414 Kit, Redundancy, Pole Mount
AS/0489 Assy, 1:1 25W CSAT
*AS/0608 Assy, Bracket Mount 25W CSAT
Refer to A.3. Single-Thread Installation.
Nomenclature
(see Note) Kit, LNA Switch
Kit, Cable, 1:1 C-Band
Kit, Waveguide CPR229
Assy, Remote Switch Cast Box
Assembly,
Figure A-14. Redundancy Configuration
Nomenclature QTY
TX
/Remote Switch
A–13
Revision 1
MN/CSAT5060.IOM
2
1
2
QTY
1
1
1
1
1
