PCI Express Board User's Manual
Applications
The PCI Express boards are suitable for many different applications, including:
• Internet/Intranet Connections
• Remote Access
• Multi-user Applications
• Industrial Automation
• Office Automation
• Telecommunications
• PC-based Vending Machines and Kiosks
• POS (Point-of-Sale) Systems
Features
The PCI Express boards have the following outstanding features:
• PCI Express ×1 compliant
• Low profile board for compact-sized PCs
• Data flow LED display onboard
• Moxa UART with 128-byte FIFO driver
• 50 bps to 921.6 Kbps transmission speed
• Supports both 4-wire and 2-wire RS-485 (CP-118EL,CP-132EL Series,CP-114EL Series)
• 2-wire RS-485 data control with ADDC™ (CP-118EL,CP-132EL Series,CP-114EL Series)
• Embedded 15 KV ESD surge protection
• Drivers for all major industrial platforms—Windows 2000, Windows XP/2003/Vista/2008
(32-bit/64-bit), DOS, Linux (32-bit/64-bit), SCO, FreeBSD 4.x/5.x
Package Checklist
The following items are included in the PCI Express board package:
• PCI Express serial board
• Document and Software CD-ROM
• Quick Installation Guide
• Low profile bracket
NOTE: Notify your sales representative if any of the above items are missing or damaged.
1-3
Introduction
