PCI Express Board User's Manual

CP-168EL Specifications

Hardware
Connectors
Comm. Controller
Interface
Bus Interface
Number of Ports
Max No. of Boards
Signals
RS-232
Performance
Baudrate
Configuration
Data Bits
Stop Bits
I/O address/IRQ
Parity
Flow Control
Power and Environment
Power Requirement
Operating Temperature
Operating Humidity
Storage Temperature
ESD Protection
Regulatory Approvals
Warranty

CP-104EL Specifications

Hardware
Connectors
Comm. Controller
Interface
Bus Interface
Number of Ports
Max No. of Boards
Signals
RS-232
Performance
Baudrate
SCSI VHDCI68
MU860 (16C550C compatible)
PCI Express × 1
8
4 (only one IRQ required)
TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND
50 bps to 921.6 Kbps
5, 6, 7, 8
1, 1.5, 2
BIOS assigned
None, Even, Odd, Space, Mark
RTS/CTS, XON/XOFF
630 mA (3.3V)
0 to 55°C (32 to 132°F)
5 to 95% RH
-20 to 85°C (-4 to 185°F)
Embedded 15 KV ESD Protection
EN55022 Class B, EN55024, EN61000-3-2, EN61000-3-3,
FCC Part 15 Class B
5 years
Female DB44
MU860 (16C550C compatible)
PCI Express × 1
4
4 (only one IRQ required)
TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND
50 bps to 921.6 Kbps
A-2
Technical Reference
