PCI Express Board User's Manual
Execute the following commands from the Linux prompt:
1.
#mount /dev/cdrom /mnt/cdrom
#cd /
#mkdir moxa
#cd moxa
#cp /mnt/cdrom/<driver directory>/driv_linux_smart_vx.x_build_yymmddhh.tgz.
#tar –xzvf driv_linux_smart_vx.x_build_yymmddhh.tgz.
2.
#cd mxser
#make clean; make install
3.
#cd /moxa/mxser/driver
#./msmknod
4.
#modprobe mxupcie
5. For CP-132EL, CP-132EL-I, CP-114EL, CP-114EL-I, use the Moxa Port Configuration Tool
to set Interface and Termination Resistor for the MUE series. The MUE series includes
CP-102E, CP-102EL, CP-132EL, CP-132EL-I, CP-114EL and CP-114EL-I.
Usage: muestty <operation> device
Device: The MUE series device node
Operation:
intf
value
For example:
To set the MUE interface
# muestty –i RS422 /dev/ttyMUE2
To set the MUE termination resistor
# muestty –t 120TERM /dev/ttyMUE2
6. Use the Moxa diagnostics utility to verify the driver status:
#cd /moxa/mxser/utility/diag
#./msdiag
7. Use the Moxa terminal utility to test the tty ports:
#cd /moxa/mxser/utility/term
#./msterm
-h Help
-g Get interface and terminator type
-i intf Set interface type with options below
-t value Set termination resistor with options below
RS232 RS-232 mode
RS422 RS-422 mode
RS4852W RS-485 2-wire mode
RS4854W RS-485 4-wire mode
NONTERM Non termination resistor
120TERM 120ohm termination resistor
3-48
Software Installation
