PCI Express Board User's Manual
Hardware Installation

CP-168EL Dimensions (Unit= mm)

102 mm (4.02 in)
46.9 mm
(1.85 in)

CP-104EL Dimensions (Unit= mm)

100 mm (3.94 in)
46.9 mm
(1.85 in)
2-3
