PCI Express Board User's Manual
CP-102E
Board Side Pin Assignments—Male DB9
CP-102E has two Male DB9 connectors on board.
Male DB9
CP-102EL
Board Side Pin Assignments—Female DB25
RS-232
13
25
1 5
6 9
1
14
Pin RS-232 Signals
1
DCD
2
RxD
3
TxD
4
DTR
5
GND
6
DSR
7
RTS
8
CTS
Pin RS-232
1
2 DCD1
GND
3
4 CTS1
5 RxD1
6
7
8
9 DTR0
10 DSR0
11 RTS0
12 TxD0
5-11
Pin Assignments
Pin RS-232
13
14
DTR1
15
16 DSR1
17 RTS1
18 TxD1
19
20
21 DCD0
22 GND
23 CTS0
24 RxD0
