PCI Card Retainers
FIGURE 4-1
Figure Legend
1
Long retainer; mfg part number: 340747400038, 60mm long
2
Short, straight retainer; mfg part number: 340747400037, 18mm long
(Note: This retainer fits the same cards as the short, curved retainer [4].)
3
Low-profile retainer; mfg part number: 340764100068, 48mm long
4
Short, curved retainer; mfg part number: 340747400039, 24mm long
(Note: This retainer fits the same cards as the short, straight retainer [2].)
The following figure shows examples of how to use these retainers with differently
sized PCI cards.
