5. See
4.4 Replacing the Air Duct
4.4.1

Removing the Air Duct

1. Prepare the server for air duct removal. See
Powering On the Server" on page
2. Facing the server, release the tab on the right of the air duct and pull upward
(
FIGURE 4-11
3. Lift the duct out of the chassis, releasing it from the pins on the left side of the
chassis, and set it aside on an antistatic mat (
Chapter 6 to return the server to operation.
).
Chapter 4
Section 4.1, "Powering Off and
4-1.
FIGURE 4-11
Replacing Motherboard Assembly Components
).
4-17
