Infopia GlucoLab Operation Manual page 11

Collecting a Drop of Blood
1. Unscrew the tip of the lanc- 2. With two fingers, pull out
ing device by turning it count- the lancet carrier and hold it
er-clockwise while holding in place.
the base firmly.
4. Twist the cap of the lancet
5. Put the tip of the lancing
off.
device back on and turn it
clockwise.
Click
7. Place the lancing device in
8. Unscrew the tip of the
place. Hold the firmly against
lancing device by turning it
the side of the finger, with the
counter-clockwise.
cap resting on the finger.
(The harder it is pressed the
deeper the puncture.) Press
the release button to take a
sample.
Discard your Blood glucose test Lancet
Push the needle into its protective cover.
20
www.infopia21.com
3. While holding the lancet
carrier, insert a new sterile
lancet into the bottom of
lancet carrier.
6. Hold the tip firmly in one
hand then pull out the slid-
ing barrel with the other
hand. This will load the
lancing device.
9. Push the lancet ejector for-
ward with the thumb and
simultaneously pull out the
sliding barrel to dispose of
the used lancet in a proper
biohazard container.
pull the lancet out and discard appropriately.
Collecting a Drop of Blood
RECOMMENDED AVAILABLE LANCETS
Some general sterilized lancets are BD-Ultra Fine, Cleanlet Fine, E-Z Ject, G-P Lite, Microlet,
Monolet, One Touch, Soft Touch, Therasense, Ultra TLC and Unilet GP.
Please note: Some lesser known lancets may not work properly due to their dimensions. Please
contact your representative to make sure that you are using proper lancets.
USING THE CLEAR TIP (AST)
1. Place the clear tip in the skin at the chosen alternative site, press and hold the continuously for a
few seconds, then push the release button to take a sample.
2. Watch through the clear tip until a sufficient blood sample is taken. If there is not enough blood,
gently massage the area until a sufficient sample has been collected.
STORAGE
Products must be stored at room temperature protected from sunlight or moisture.
CLEANING AND DISINFECTION
Clean and wipe the outside of the lancing device a minimum of once a week with a soft cloth,
dampened with mild soap and water. Wash the adjustable tip and the clear tip once a week with
mild soap. Do not immerse in liquid.
WARRANTY
The lancing device has a 2-year warranty from the date of purchase. A malfunctioning device
should be returned to the following address:
GMMC
Room No. 1112, Ace Tower 9th Bldg., 345-30, Kasan-Dong, Kumchon-Ku, Seoul, South Korea
Tel : +82 2 2104 0470
Fax : +82 2 2104 0472
GMMC, S.L.
C/Jordi de S. Jordi 13, 6-23 46022 Valencia SPAIN
Tel : +34 963 691 484
Fax: +34 961 125 949
U.K. Distributor: Neon Diagnostics Ltd.
Untis 7&8, Swanbridge Industrial Park, Black Croft Road, Witham, Essex, CM8 3YN
CUSTOMER CARE LINE: 01376 500 720
www.neondiagnostics.co.uk
21
