MANUAL INTRODUCTION

The information in this manual is intended as an installation and commissioning guide for
the standard range of vandal resistant door panels, to be used with standard AC buzzer
telephones or with vandal resistant video panels using the Art.890 controller. This manual
should be read carefully before the installation commences. Any damage caused to the
equipment due to faulty installations where the information in this manual has not been
followed is not the responsibility of Videx Security Ltd.
VIDEX run free training courses for engineers who have not installed this system before.
Technical help is also available on 0191 224 3174 during office hours or via e-mail
tech@videx-security.com.

SYSTEM INTRODUCTION

This system can be used for single entrances or multiple entrances. The system has no
limit on the number of apartments for which it can control or the number of entrance points
that can be connected together, although we suggest using this system on small to
medium sized installation of no more than 20 apartments and three entrances.

SYSTEM COMPONENTS

A standard audio system will comprise of a door panel, power supply and audio
telephones. A standard video system will comprise of a door panel, video controller, power
supply, video splitters and videophones. The individual parts are described below.
DOOR PANELS
A vandal resistant door panel will consist of an amplifier module, button connector board
and 'n' number of buttons.
Amplifier module (Art.437 or Art.537)
Connection
1 Receive speech from apartment
2 Transmit speech to apartment
3 +12Vdc input
4 0V (Ground)
Camera module (Art.830 & 830C)
Connection
I +20Vdc input 200mA
F1 0V
V Centre core of coax video cable
M Screen of coax video cable
SB +8-12Vdc camera heater
Speech volume adjustments are carried out at the door panel using a small trimmer driver.
Adjustment for
speech volume level
at the door station
PAGE 4 of 24 AUDIO/VIDEO VANDAL RESISTANT TECHNICAL MANUAL
Function
Function
(400mA - 830C)
Connector PCB (CB)
Connection
LOCK Spare connector terminals
CB Common of call buttons
A Spare connection terminal
1 Call button 1 connection
2 Call button 2 connection
3 Call button 3 connection
4 Call button 4 connection
5 Call button 5 connection
6 Call button 6 connection
7 Call button 7 connection
8 Call button 8 connection
9 Call button 9 connection
10 Call button 10 connection
TRADE Trade button connections
Adjustment for
speech volume at the
Function
apartment
