Maximum acceptable resistance for terminals T, G2, H1 = 10Ω and for terminals A, +8, F, F1 & I = 6Ω and
for terminals SE & F2 = 3Ω
V is the centre core of the coax and M is the screen.
The transformer should be mounted next to the Art.890 and connected using 1mm² cores
Connections from the Art.890 controller to the videophone.
Connections 50m
Numbers in brackets are
those of the videophone
back plate. Without
brackets are signal
+12(1) 0.35mm²
0.35mm²
TV1(2)
TV2(3) 0.35mm²
1(4) 0.35mm²
2(5) 0.35mm²
3(6) 0.35mm²
4(7) 0.35mm²
5(8) 0.35mm²
0.35mm²
6(9)
7(10) 0.35mm²
V(11) Standard quality
M(12) 75Ω Coax cable
R(13) 0.35mm²
C(14) 0.35mm²
-(15) 0.35mm²
T(16) 0.35mm²
1T(17) 0.35mm²
2T(18) 0.35mm²
When ever possible connection 3(6) should be twisted with connection 5(8) and connection 4(7) should be
twisted with connection 5(8) as pairs.
Maximum acceptable resistance for all terminals except 1(4) & 6(9) = 10Ω and terminals 1(4) & 6(9) = 6Ω
V is the centre core of the coax and M is the screen.

AUDIO SYSTEM BLOCK DIAGRAM

Note: Additional cores will be required for auxiliary devices such as push to exit buttons,
fireman switches, proximity access control etc.
PAGE 14 of 24 AUDIO/VIDEO VANDAL RESISTANT TECHNICAL MANUAL
100m 200m
0.35mm² 0.5mm²
0.35mm² 0.5mm²
0.35mm² 0.5mm²
0.5mm² 1.0mm²
0.35mm² 0.5mm²
0.35mm² 0.5mm²
0.35mm² 0.5mm²
0.35mm² 0.5mm²
0.5mm² 1.0mm²
0.35mm² 0.5mm²
Medium quality Good quality
75Ω Coax cable 75Ω Coax cable
0.35mm² 0.5mm²
0.35mm² 0.5mm²
0.35mm² 0.5mm²
0.35mm² 0.5mm²
0.35mm² 0.5mm²
0.35mm² 0.5mm²
Art.3021, 3101, 3102
5
300m 400m
0.75mm² 1.0mm²
0.75mm² 1.0mm²
0.75mm² 1.0mm²
1.5mm² 2.0mm²
0.75mm² 1.0mm²
0.75mm² 1.0mm²
0.75mm² 1.0mm²
0.75mm² 1.0mm²
1.5mm² 2.0mm²
0.75mm² 1.0mm²
Good quality High quality
75Ω Coax 75Ω Coax
cable cable
0.75mm² 1.0mm²
0.75mm² 1.0mm²
0.75mm² 1.0mm²
0.75mm² 1.0mm²
0.75mm² 1.0mm²
0.75mm² 1.0mm²
5
5
