Art.3313
The Art.3313 (3413 for colour) includes a lock release push button and two dry contact push
to make spare push buttons for other services. An Art.3980 back plate is required with this
videophone.
CONNECTIONS:-
Function
1
+12V out to power video splitter
2
Not used
3
Spare button
4
+20V power input
5
Door release command
6
Transmit speech to door panel
7
Receive speech from door panel
8
0V (Ground)
9
Not used
10
Local call tone input
11
Coax centre core or non-coax sync-
12
Coax Screen or non-coax Sync+
13
Switched +12 for door open LED
14
Select input to switch on videophone
15
Call tone input
16
Common of spare buttons
17
Spare button
18
+12V to power videophone privacy
DIP SWITCH SETTINGS
8 Way dip switch (Switches 1 – 5)
Mute Duration time
Time
15 Minutes
30 Minutes
2 Hours
4 Hours
8 Hours
8 Way dip switch (Switch 6)
Mute LED
Switch
Fixed
Flashing
4 Way Dip Switch (Switches 1 & 2)
S Button Operation
Switch
Camera recall
Dry contact
3 Way Dip Switch
VIDEO MODE continued
Switch
Coax
Non-Coax
PAGE 11 of 24
1
2
ON
OFF
OFF
ON
OFF
OFF
OFF
OFF
OFF
OFF
6
OFF
ON
1
2
ON
OFF
OFF
ON
AUDIO/VIDEO VANDAL RESISTANT TECHNICAL MANUAL
3
OFF
OFF
ON
OFF
OFF
8 Way dip switch (Switches 7 & 8)
°° Button Operation
Switch
Camera recall
Dry contact
4 Way Dip Switch (Switches 3 & 4)
VIDEO MODE
Switch
Coax
Non-Coax
1
2
OFF
OFF
ON
ON
4
5
OFF
OFF
OFF
OFF
OFF
OFF
ON
OFF
OFF
ON
7
8
ON
OFF
OFF
ON
3
4
ON
ON
OFF
OFF
3
OFF
ON
VER1.1
