3D connections

3D sources up to 60Hz requiring frame doubling and left/right interleaving

1. Connect to either of the following inputs on the connection panel:
•
HDMI 1
•
HDMI 2
•
HDBaseT
2. Set in the menu to match the format of the incoming signal. Choose from
3D Format 3D
Top and Bottom .
The Frame Packing format is automatically detected by the projector.

Frame sequential 3D sources up to 120Hz

•
Connect to the DVI input.
The Frame Sequential format is automatically detected by the projector and is supported on the DVI input only.

Dual Pipe 3D

1. Connect the left eye output to the
2. Set 3D Format in the 3D menu to
Rev B July 2014
socket and the right eye output to the
HDMI 1
Dual-Pipe .
1
2
HDBaseT
1
DVI
2
3 HDMI 1 / Dual Pipe LEFT
4 HDMI 2 / Dual Pipe RIGHT
SIGNAL INPUTS
,
Auto Side by Side (Half)
socket.
HDMI 2
3 4
For a complete listing of all
supported signal input modes, see
Appendix C: Supported Signal
Input Modes
Guide.
and
For a complete listing of pin
configurations for all signal and
control connectors, see
E: Wiring Details
Guide.
