Digital Projection
M-Vision 930 Series
Projector Overview
Front and rear views
Air inlet
1
Lens
2
Front infrared window
3
Air inlet
4
Connection panel
5
Control panel
6
Rear infrared window
7
Lamp enclosures with air outlets
8
Mains inlet with power button and voltage switch
9
Air outlet
10
Adjustable feet
11
Air inlet
12
Rev B July 2014
PROJECTOR OVERVIEW
1
2
3
4
Front view
5
6
7
8
9
10
Rear view
Installation and Quick-Start Guide
Notes
11
12
5
