Control panel indicators

During power on, all LED indicators become lit while the projector is
running a self test.
At the end of the self test only the
STANDBY
When the projector goes from STANDBY to ON mode, the
indicator is switched off and the ON indicator is lit.
The indicator flashes during cool down.
ON
Indicators
ON
1
ERROR
2
STANDBY
3
Error codes
If the projector detects an error, the red
For example, if the lamp door is left open, the
error condition is corrected.
Condition ERROR indicator behavior
Lamp fail Flashes once, then pauses, then repeats.
Lamp door open Flashes twice, then pauses, then repeats.
Fan failure Flashes three times, then pauses, then repeats.
Over temperature Flashes four times, then pauses, then repeats.
Filter failure Flashes five times, then pauses, then repeats.
System error On.
Rev B July 2014
indicator remains lit.
STANDBY
MENU
ON
1
indicator will flash as shown in the chart below.
ERROR
indicator will flash twice followed by a pause, then the sequence will repeat until the
ERROR
