Digital Projection Titan Super Quad Series User Manual
High brightness digital video projector
installation and quick-start guide
connection guide
operating guide
reference guide
Hide thumbs
Also See for Titan Super Quad Series:
- User manual (215 pages) ,
- User manual (197 pages) ,
- Important information manual (30 pages)
Table of Contents
Advertisement
Quick Links
Download this manual
See also:
User Manual
Advertisement
Chapters
Table of Contents
Related Manuals for Digital Projection Titan Super Quad Series
Summary of Contents for Digital Projection Titan Super Quad Series
- Page 1 USER GUIDES INSTALLATION AND QUICK-START GUIDE Titan Super Quad Series CONNECTION GUIDE OPERATING GUIDE Titan Quad 2000 Series REFERENCE GUIDE Titan Quad Series Titan 800 Series High Brightness Digital Video Projector Rev F November 2012 112-671F...
- Page 2 NOTE: this symbol indicates that there is some important information that you should read. Product revision Because we at Digital Projection continually strive to improve our products, we may change specifications and designs, and add new features without prior notice.
- Page 3 INSTALLATION AND QUICK-START GUIDE Titan Super Quad Series Titan Quad 2000 Series Titan Quad Series Titan 800 Series High Brightness Digital Video Projector Rev F November 2012...
-
Page 4: Table Of Contents
Digital Projection CONTENTS Installation and Quick-Start Guide Titan Quad, & Titan 800 Series CONTENTS What’s In The Box? ................Inst 1 Getting to Know the Projector .............Inst 2 Front and rear views ................Inst 2 Remote control ..................Inst 2 Control panel indicators ................Inst 3 Connection panel indicators ..............Inst 3... -
Page 5: What's In The Box
Digital Projection WHAT’S IN THE BOX? Installation and Quick-Start Guide Titan Quad, & Titan 800 Series What’s In The Box? Notes Make sure your box contains everything listed. If any pieces are missing, contact your dealer. You should save the original box and packing materials, in case you ever need to ship your projector. -
Page 6: Getting To Know The Projector
Titan Quad, & Titan 800 Series Getting to Know the Projector Notes Remote control Front and rear views The projector uses the standard Digital Projection infra-red remote control. Transmit Only the controls shown highlighted indicator are used on this projector. -
Page 7: Control Panel Indicators
Digital Projection GETTING TO KNOW THE PROJECTOR Installation and Quick-Start Guide Titan Quad, & Titan 800 Series Control panel indicators Notes The indicators on the control panel are as follows: Power Shutter Power off = NO POWER Only the controls shown highlighted are used on this projector. -
Page 8: Positioning The Screen And Projector
Digital Projection POSITIONING THE SCREEN AND PROJECTOR Installation and Quick-Start Guide Titan Quad, & Titan 800 Series Positioning The Screen And Projector Notes Always allow the projector • Install the screen, ensuring that it is in the best position for viewing by your audience. -
Page 9: Fitting The Lens
Digital Projection FITTING THE LENS Installation and Quick-Start Guide Titan Quad, & Titan 800 Series Fitting The Lens Notes • Turn the lens release lever clockwise so that it is pointing upwards, to open the lock fully. Always allow the lamp to cool for •... -
Page 10: Operating The Projector
Digital Projection OPERATING THE PROJECTOR Installation and Quick-Start Guide Titan Quad, & Titan 800 Series Operating The Projector Notes Switching the projector on • Connect the power cable between the mains supply and the projector. Switch on at the switch next to the power connector. -
Page 11: Adjusting The Lens
Digital Projection OPERATING THE PROJECTOR Installation and Quick-Start Guide Titan Quad, & Titan 800 Series Adjusting the lens Notes The lens can be adjusted using the Lens menu, or: Zoom When any of the three lens adjustment keys is pressed, the blue •... -
Page 12: Switching The Projector Off
Digital Projection OPERATING THE PROJECTOR Installation and Quick-Start Guide Titan Quad, & Titan 800 Series Switching the projector off Notes Press on the remote control or the control panel, and hold for 3 seconds, to switch the projector OFF. The power indicator on the control panel will show amber, the lamp will be off and the projector will be in STANDBY mode. -
Page 13: Rev F November
CONNECTION GUIDE Titan Super Quad Series Titan Quad 2000 Series Titan Quad Series Titan 800 Series High Brightness Digital Video Projector Rev F November 2012... - Page 14 Digital Projection CONTENTS Connection Guide Titan Quad & Titan 800 Series CONTENTS Wiring Details ..................Conn 5 Signal Inputs and Outputs Signal inputs and outputs ..............Conn 5 ............Conn 1 Input 1: VGA ................Conn 5 Rear Connection Panel ............... Conn 1 Input 2: HDMI ................
-
Page 15: Signal Inputs And Outputs
Digital Projection SIGNAL INPUTS AND OUTPUTS Connection Guide Titan Quad & Titan 800 Series Signal Inputs and Outputs Notes Rear Connection Panel For a complete listing of pin configurations for all signal and VGA (input 1) control connectors, see Wiring •... -
Page 16: Side Connection Panel
Digital Projection SIGNAL INPUTS AND OUTPUTS Connection Guide Titan Quad & Titan 800 Series Side Connection Panel Notes DVI (input 9) • Single or Dual Link DVI-D input, or For a complete listing of pin • configurations for all signal and For Twin-Link DVI, Input 9 (DVI) is the Main input, Input 10 (DVI/HDMI) is the Sub input. -
Page 17: 3D Connections
Digital Projection SIGNAL INPUTS AND OUTPUTS Connection Guide Titan Quad & Titan 800 Series 3D Connections Notes 3D sources up to 60Hz requiring frame doubling and left/right interleaving • Connect to any of the Inputs on the Rear Connection Panel. -
Page 18: Control Connections
LAN) should be used at any one • time. The Service Port port is used to download, via USB, firmware updates issued from time to time by Digital Projection. Note that plugging in the remote control cable will disable the infra- Wired remote control red. -
Page 19: Wiring Details
Digital Projection WIRING DETAILS Connection Guide Titan Quad & Titan 800 Series Wiring Details Notes Signal inputs and outputs For full details of all input settings, see the Operating Guide. Input 1: VGA 15 way D-type connector VGA: pin view of female connector... -
Page 20: Input 2: Hdmi
Digital Projection WIRING DETAILS Connection Guide Titan Quad & Titan 800 Series Input 2: HDMI Notes 19 way type A connector TMDS Data 2+ TMDS Data 2 Shield For full details of all input settings, HDMI: pin view of panel connector TMDS Data 2- see the Operating Guide. -
Page 21: Input 3: Dvi
Digital Projection WIRING DETAILS Connection Guide Titan Quad & Titan 800 Series Input 3: DVI Notes 24 way D-type connector Pin 1 TMDS data 2− Digital red− (link 1) High-bandwidth Digital Content Pin 2 TMDS data 2+ Digital red+ (link 1) -
Page 22: Input 4: 3G-Sdi
Digital Projection WIRING DETAILS Connection Guide Titan Quad & Titan 800 Series Input 4: 3G-SDI Notes 75 ohm BNC 3G-SDI signals are very high 3G-SDI connector speed digital signals which require better quality coaxial cable than Input 5: Composite 1 conventional analogue video. -
Page 23: Input 9: Main/Dvi
Digital Projection WIRING DETAILS Connection Guide Titan Quad & Titan 800 Series Input 9: MAIN/DVI Notes 24 way D-type connector Pin 1 TMDS data 2− Digital red− (link 1) High-bandwidth Digital Content Pin 2 TMDS data 2+ Digital red+ (link 1) -
Page 24: Input 10: Sub/Hdmi
Digital Projection WIRING DETAILS Connection Guide Titan Quad & Titan 800 Series Input 10: SUB/HDMI Notes 19 way type A connector TMDS Data 2+ For full details of all input settings, TMDS Data 2 Shield see the Operating Guide. HDMI: pin view of panel connector... -
Page 25: Control Connections
Digital Projection WIRING DETAILS Connection Guide Titan Quad & Titan 800 Series Control connections Notes Update port RJ45 socket For full details of all network settings, see the Operating Guide. Update port Service port USB type B socket Pin 1... -
Page 26: Rs232
Digital Projection WIRING DETAILS Connection Guide Titan Quad & Titan 800 Series RS232 Notes 9 way D-type connector 1 unused Only one remote connection (RS232 2 Received Data (RX) or LAN) should be used at any one time. RS232: 3 Transmitted Data (TX) -
Page 27: Operating Guide
OPERATING GUIDE Titan Super Quad Series Titan Quad 2000 Series Titan Quad Series Titan 800 Series High Brightness Digital Video Projector Rev F November 2012... - Page 28 Lamps menu ..................Op 16 ..................Op 1 Titan 800 series ................Op 16 Menus and sub-menus ................Op 1 Titan Super Quad series, Titan Quad 2000 series and Titan Quad series Drop-down lists ..................Op 2 Op 16 Sliders ...................... Op 3 Setup menu ....................
- Page 29 Digital Projection CONTENTS Operating Guide Titan Quad & Titan 800 Series CONTENTS (continued) Web Configuration Utility ..............Op 30 Menu examples..................Op 30 Using the Discovery Tool to view your network ......... Op 32 Rev F November 2012...
-
Page 30: Using The Menus
Digital Projection USING THE MENUS Operating Guide Titan Quad & Titan 800 Series Using The Menus Notes Use the buttons on the projector control panel or on the remote control, to access the menu system. Some menu items may not be •... -
Page 31: Drop-Down Lists
Digital Projection USING THE MENUS Operating Guide Titan Quad & Titan 800 Series Drop-down lists Notes To use a drop-down list, press , select an item using , then press again or press to exit without changing. Some menu items may not be available due to settings in other menus. -
Page 32: Sliders
Digital Projection USING THE MENUS Operating Guide Titan Quad & Titan 800 Series Sliders Notes To use a slider, press to adjust it. Some menu items may not be available due to settings in other menus. These will be grayed out on the actual menu. -
Page 33: Editing Fields
Digital Projection USING THE MENUS Operating Guide Titan Quad & Titan 800 Series Editing fields Notes Some features require a text or numeric field to be edited. Some menu items may not be • To edit a field, first select it using... -
Page 34: A Tour Of The Menus
Digital Projection A TOUR OF THE MENUS Operating Guide Titan Quad & Titan 800 Series A Tour Of The Menus Notes See also Using the Menus earlier in this guide and Menu Map later in Main menu this guide. •... -
Page 35: Lens Menu
Digital Projection A TOUR OF THE MENUS Operating Guide Titan Quad & Titan 800 Series Lens menu Notes Zoom Main Menu To move the lens in or out: Lens Select Zoom In Zoom Out , then press When the image is the desired size, select... -
Page 36: Lens Presets
Digital Projection A TOUR OF THE MENUS Operating Guide Titan Quad & Titan 800 Series Lens Presets Notes This menu allows you to save up to five custom lens presets, which you can recall later. Main Menu Lens Lens Presets... -
Page 37: Image Menu
Digital Projection A TOUR OF THE MENUS Operating Guide Titan Quad & Titan 800 Series Image menu Notes • Brightness, Contrast, Gamma, Hue and Saturation Set the slider or select from the drop-down list as required, to improve the quality of the image. -
Page 38: Color Menu
Digital Projection A TOUR OF THE MENUS Operating Guide Titan Quad & Titan 800 Series Color menu Notes Gamut Main Menu Peak gives you the brightest possible image. Color Choose HDTV for high definition standards and SDTV for standard definition standards. -
Page 39: Geometry Menu
Explained in the Reference Guide. • Warp Map Using an external Digital Projection computer application, up to eight customised warp maps can be created and uploaded to the projector. If Warp is selected, and any warp maps have been uploaded, you can select from the drop-down list. -
Page 40: Size & Position
Digital Projection A TOUR OF THE MENUS Operating Guide Titan Quad & Titan 800 Series Size & Position Notes • Enable • to choose: Setting Main Menu Geometry , in which case these settings will be applied to all signals on all inputs. -
Page 41: Edge Blend Menu
Digital Projection A TOUR OF THE MENUS Operating Guide Titan Quad & Titan 800 Series Edge Blend menu Notes When several projectors are used to create a large tiled image, the edges need to be blended to avoid the overlaps appearing brighter than the rest of the image. The Edge Blend menu is available only when >... - Page 42 Digital Projection A TOUR OF THE MENUS Operating Guide Titan Quad & Titan 800 Series Blend Width Notes • Use this to set the width of the blended regions. To apply the settings in these menus, use the command at the bottom of each page.
-
Page 43: Pip Menu
Digital Projection A TOUR OF THE MENUS Operating Guide Titan Quad & Titan 800 Series PIP menu Notes Two images can be combined, in three different ways using this feature. The PIP menu is available only when Setup > System >... -
Page 44: 3D Menu
Digital Projection A TOUR OF THE MENUS Operating Guide Titan Quad & Titan 800 Series 3D menu Notes • 3D Enable as required. • Use the Frame Rate Multiplier to reduce flicker when the incoming 3D video signal has a low Main Menu frame rate. -
Page 45: Lamps Menu
Main Menu Lamp Set the slider to vary the between 80% and 100%. Power Titan Super Quad series, Titan Quad 2000 series and Titan Quad series to choose between In the modes, the Operation All Lamps... -
Page 46: Setup Menu
Digital Projection A TOUR OF THE MENUS Operating Guide Titan Quad & Titan 800 Series Setup menu Notes • Orientation Depending on how the projector is mounted, select the appropriate setting from the drop-down Main Menu Setup list. • Latency Affects interlaced sources only. -
Page 47: Input Configuration
Digital Projection A TOUR OF THE MENUS Operating Guide Titan Quad & Titan 800 Series Input Configuration Notes This menu allows adjustment of various technical parameters specific to each of the signal inputs, regardless of which input is being used. Main Menu •... -
Page 48: Network
Digital Projection A TOUR OF THE MENUS Operating Guide Titan Quad & Titan 800 Series Network Notes The fields at the bottom of the menu show the current settings. • if the IP Address is to be assigned by a DHCP server, or if it is to be set here. -
Page 49: On Screen Display
Digital Projection A TOUR OF THE MENUS Operating Guide Titan Quad & Titan 800 Series On Screen Display Notes • Select a display Language from the drop-down list. • The menus will disappear if no buttons are pressed within the... -
Page 50: System
Digital Projection A TOUR OF THE MENUS Operating Guide Titan Quad & Titan 800 Series System Notes • Configuration : switch between Edge Blend The other settings in this menu are provided mainly to allow control from the Web Configuration Utility. -
Page 51: Information Menu
Digital Projection A TOUR OF THE MENUS Operating Guide Titan Quad & Titan 800 Series Information menu Notes This menu gives information about lamp operating times, software and hardware configuration, input source and network settings. Please note that the values... -
Page 52: Menu Map
Digital Projection MENU MAP Operating Guide Titan Quad & Titan 800 Series Menu Map Notes Main Menu Sub Menus Some of the information in this menu map is summarised. See the actual Input Selection menu on the projector for full detail. -
Page 53: Image
Digital Projection MENU MAP Operating Guide Titan Quad & Titan 800 Series Notes Main Menu Sub Menus Some of the information in this menu Image map is summarised. See the actual Brightness (slider, value range -50 ~ 50 [0]) menu on the projector for full detail. -
Page 54: Geometry
Digital Projection MENU MAP Operating Guide Titan Quad & Titan 800 Series Notes Main Menu Sub Menus Some of the information in this menu Geometry map is summarised. See the actual Aspect Ratio Source, Fill Display, Fill & Crop, Anamorphic, TheaterScope menu on the projector for full detail. -
Page 55: Edge Blend
Digital Projection MENU MAP Operating Guide Titan Quad & Titan 800 Series Notes Main Menu Sub Menus Some of the information in this menu Edge Blend map is summarised. See the actual Array Width (slider, value range 1 ~ 4) menu on the projector for full detail. -
Page 56: Pip
Digital Projection MENU MAP Operating Guide Titan Quad & Titan 800 Series Notes Main Menu Sub Menus Some of the information in this menu map is summarised. See the actual Option Off, PIP, PAP, POP menu on the projector for full detail. -
Page 57: Setup
Digital Projection MENU MAP Operating Guide Titan Quad & Titan 800 Series Notes Main Menu Sub Menus Some of the information in this menu Setup map is summarised. See the actual Orientation Desktop Front, Desktop Rear, Ceiling Front, Ceiling Rear menu on the projector for full detail. -
Page 58: Information
Digital Projection MENU MAP Operating Guide Titan Quad & Titan 800 Series Notes Main Menu Sub Menus Some of the information in this menu Information map is summarised. See the actual Lamps menu on the projector for full detail. Lamp 1 Hours, Lamp 1 Starts, Lamp 2 Hours, Lamp 2 Starts... -
Page 59: Menu Examples
Digital Projection WEB CONFIGURATION UTILITY Operating Guide Titan Quad & Titan 800 Series Web Configuration Utility Notes The LAN IP Address of the projector can be set by using the Network submenu, which can be found in the Setup menu. For full details of how to use the... - Page 60 Digital Projection WEB CONFIGURATION UTILITY Operating Guide Titan Quad & Titan 800 Series Examples (continued) Notes • Sliders are represented by similar sliders, as in the Array Width Array Height sliders shown here. For full details of how to use the •...
-
Page 61: Using The Discovery Tool To View Your Network
Digital Projection WEB CONFIGURATION UTILITY Operating Guide Titan Quad & Titan 800 Series Using the Discovery Tool to view your network Notes The Discovery Tool allows you to view the IP addresses of all projectors in your network. The tool opens the following page in your browser:... -
