3. Notebook Computer
This setup has been tested on the following Notebook Computers:
1. Compaq Presario X1000 ( No longer available)
2. HP Compaq nx7010 ( No longer available)
3. Sony VAIO VGN-FS754
4. Sony VAIO VGN-FS540
These Notebook Computers have integrated Intel Centrino Wireless Networking.
Windows XP Professional should automatically detect the Portable System's
"sonarlink" as an available wireless network
The HP Compaq Business Notebook nx7010 has integrated Intel Centrino
Wireless Networking. Windows XP Professional should automatically detect the
Portable System's "sonarlink" as an available wireless network.
1.
Open the laptop's "Wireless Network Connection" properties window (see
below).
2.
If the Portable System is running, the "sonarlink" should be displayed in the
"Available networks" list.
3.
Select "sonarlink" and click the "Configure" button.
4.
In the "sonarlink properties" window, verify (Uncheck if necessary) that the
boxes for "Data Encryption" and "Network Authentication" are Unchecked,
then click "OK".
5.
In the Wireless Network Connection" properties window, click the "Advanced"
button.
6.
In the "Advanced" window, check the Radio Button for "Computer-to-computer
(ad hoc) networks only", and check the box to "Automatically connect to non-
preferred networks", then click "Close".
7.
In the Wireless Network Connection" properties window, click the "OK" button.
A
A
P
P
E
N
P
P
E
N
A-13
A
–
W
S
A
–
W
S
D
I
X
I
R
E
L
E
S
S
E
D
I
X
I
R
E
L
E
S
S
E
990-0000058-1000
Rev. B
T
U
P
T
U
P
