2.

Overview

The "portable" deck unit is splash proof and constructed of high-impact structural
polypropylene material. The deck unit provides the interface and acquisition hardware to
the tow fish. The firmware inside the deck unit interfaces to the notebook computer via
TCP/IP based Ethernet or wireless connection. While communication with the deck unit
the laptop computer is running DISCOVER acquisition software displaying and
recording data.
2.1.

Product Specifications

2.1.1.

Supplied Components

• Notebook Computer (No laptop optional)
• Discover 3100 Software
• 3100P Portable Processor case with integral interface and electronics components
• AC Power cable
• DC Power & Ethernet cable
• Spares Kit
• Manuals
2.1.2.

Physicals

Size : 390 D x 490 W x 190 H (mm), 15.2 D x 19.2 W x 7.3 H (inches)
Weight : 14.5 kg (31.8 lbs) with Notebook (Sony VAIO), 11.6 kg (25.5 lbs) without
Notebook
Construction : High-impact structural polypropylene
Color : Yellow
Sealing : Watertight cover O-ring seal with purge valve
990-0000058-1000
3
1
0
0
3
1
0
0
Rev F
P
-
T
O
P
S
I
D
E
P
R
O
C
E
S
S
O
R
P
-
T
O
P
S
I
D
E
P
R
O
C
E
S
S
O
R
Page 14
