3100P Portable Topside Unit Case

The portable topside unit case supplied is based on the Hardigg "Storm Case" and
provides a waterproof enclosure for the sonar and interface electronics, and Tow Vehicle
power supply. Power, Tow Vehicle cable and Ethernet cable connectors are mounted on a
recessed, waterproof panel, with LED indicators and ON/OFF switch. A functional block
diagram of the components contain within portable topside unit case is shown in Figure
3-1 3100P Portable Topside Unit Functional Block Diagram.
For an assembly drawing of the portable topside unit case refer to the Internal Hardware
Section of this manual.
