7.1.

Wireless Network Adapter TCP/IP Address:

For more information on wireless setup and configuration please refer to Appendix B, "56xP
System – Wireless Setup"
7.1.1.
Wireless Networking
The IP Address for Wireless Networking is fixed at 192.9.0.100, and should not be changed.
Ethernet LAN The IP Address for Ethernet LAN is fixed at 192.9.0.99, and should not be
changed. The Ethernet LAN can be configured for Auto or 100Mbit/s link speed for short
(8m/25ft) cables. For longer cables EdgeTech recommends a setting of 10Mbit/s, Half Duplex
mode.
7.1.2.
3100P Topside
The TCP/IP Ethernet capable components of the 3100P Topside are shown below. The IP
Addresses for these components are fixed and should not be changed.
990-0000058-1000

Figure 7-2 Wireless TCP/IP Address

Rev E
3
1
0
0
P
-
T
O
P
S
I
D
E
P
R
O
C
E
S
S
O
3
1
0
0
P
-
T
O
P
S
I
D
E
P
R
O
C
E
S
S
O
Page 49
