N
:
OTES
This message should only be used if it is imperative that the event mark
number be externally controlled, otherwise the $EGEVT message should be
used. If the mark number sent is the same as the current mark number the
message will be ignored.
A shortcut to the Windows HyperTerminal application is provided to check the
navigation input.
need to modify the properties if not running at 4800 baud. A sample display
is shown below.
$GPGLL,2600.0100,N,800000.0000,W,151228.99,A*67
$GPVTG,315.65,T,314.15,M,3.8,N,7.0,K*48
$GPZDA,151229.25,28.08,1997,06,00*45
$EGEVT,M,EventNo,Time,Position,Annotation,*73
$GPGLL,2600.0125,N,8000.0025,W,151229.50,A*84
$GPVTG,316.65,T,315.15,M,3.9,N,7.1,K*33
$GPZDA,151229.75,28.08,1997,06,00*45
$EGEVT,M,EventNo,Time,Position,Annotation,*48
$GPGLL,2600.0150,N,800000.0050,W,151229.99,A*12
$GPVTG,315.85,T,314.65,M,3.8,N,7.0,K*58
$GPZDA,151230.25,28.08,1997,06,00*72
$EGEVT,M,EventNo,Time,Position,Annotation,*48
N
:
OTES
The number of incoming strings should be limited to the five mentioned
above.
For accurate fixes, the navigation strings should be updated once a second
or faster.
990-0000058-1000
You must quit the application before running, and may
Rev F
3
1
0
0
P
-
T
O
P
S
I
D
E
P
R
O
C
E
S
S
O
3
1
0
0
P
-
T
O
P
S
I
D
E
P
R
O
C
E
S
S
O
Page 33
