4.3.1.

Inputs

The following are the approved NMEA sentences recommended for use with the
DISCOVER based systems.
GLL – Geographic Position – Latitude/Longitude
Latitude and Longitude of the present vessel position, time of position fix and status.
GLL,xxxx.xxx,a,yyyyyy.yyy,b,hhmmss.ss,A*hh<CR><LF>

Table 4-3 GLL- Geographic Position-Latitude/Longitude

ARGUMENT
xxxx.xxx
Degrees|Minutes.decimal - 2 fixed digits of degrees, 2 fixed digits of
minutes and a variable number of digits for decimal fractions of minutes.
Leading zeros always included for degrees and minutes to maintain fixed
length.
a
N for North Latitude or S for South Latitude
yyyyy.yyy
Degrees|Minutes.decimal - 3 fixed digits of degrees, 2 fixed digits of
minutes and a variable number of digits for decimal fractions of minutes.
Leading zeros always included for degrees and minutes to maintain fixed
length.
b
E for East Longitude or W for West Longitude
990-0000058-1000

Table 4-2 NMEA Approved Sentence Structure

HEX
Start of Sentence
Dummy characters to start the Address Field (e.g. GP), not
used by EdgeTech products.
Sentence Formatter. Mnemonic code identifying the data
type and the string format of the successive fields.
Field Delimiter.
Checksum fields. If it is followed by a null field, it is all
that remains to indicate no data in the field.
Data Sentence Block. Data field(s) preceded and separated
by delimiters.
Optional Checksum Delimiter.
Optional Checksum Field
Terminates Sentence
DESCRIPTION
Rev F
