4.4.
Printer Connection
Note: Printing is not supported at this time on the 3100P portable topside.
The information contained in section 4 is for future reference.
Various types of ETHERNET thermal continuous printers may be interfaced in the
future. To install a supported model, connect the printer cable to the parallel port. A
PCMCIA parallel port card is provided to interface to the printers in the following table:
4.4.1.
EPC model GSP-1086
The EPC model GSP-1086-NT is a widely used gray scale continuous printer in the
marine industry. It provides high quality images on a ten inch thermal printhead. The
software defined control panel makes the printer configurable to a wide range of
applications.
Paper
Data point
Paper roll length
Film Length
Paper/Film Width
Resolution
Tone Shades
Interface
Plot Speed
990-0000058-1000
Table 4-15 ETHERNET Printers
Printers
iSys V8.5-ETHERNET
EPC 1086-NT
Table 4-16 EPC 1086 Specs
Thermal or plastic
2048
150ft(4507m)
130ft (39.6m)
10.48in (26.6cm)
203 dots per inch (8 dots/mm)
Up to 256 gray scales
Parallel
43 ms@ 64 shades
Rev F
3
1
0
0
P
-
T
O
P
S
I
D
E
P
R
O
C
E
S
S
O
3
1
0
0
P
-
T
O
P
S
I
D
E
P
R
O
C
E
S
S
O
Page 34
