4.

Notebook Computer

The Notebook Computer runs the Discover 3100 Software. This provides for control,
storage and display of the Tow Vehicle data. The data is presented on a gray scale
waterfall display and is stored in SEGY format on hard disk. A user supplied GPS with
NMEA interface strings is required for positioning data.
See:
http://www.edgetech.com/topsidelevel3discover.html
4.1.

Navigation Interface

The following information describes the serial port interface parameters for acquiring
navigation strings from a connected GPS unit or integrated navigation computer to the
serial port. Edgetech supplies a USB to serial cable for acquiring navigation data.
4.2.

Serial Port Parameters

The serial navigational com port is configured using the Discover Setup.

Figure 4-1 Discover Navigation Input Setup Wizard

990-0000058-1000
3
1
0
0
3
1
0
0
Rev F
P
-
T
O
P
S
I
D
E
P
R
O
C
E
S
S
O
R
P
-
T
O
P
S
I
D
E
P
R
O
C
E
S
S
O
R
Page 24
