1.

Introduction

The 3100P Portable Topside Processor provides an interface between a laptop computer
running EdgeTech's DISCOVER 3100P Sub-bottom Sonar acquisition software, and a
model SB-424 or SB-216S towfish. The end user need only supply a source of GPS data
and either AC or DC power to complete the acquisition package. The complete system
with the 3100P and towfish is the Model 3100P Sub-bottom Sonar System.
The 3100P unit is a self contained, portable unit with all interface and power supply
electronics housed within a rugged, waterproof (when the lid is closed) Storm ® case.
There is space inside the closed unit to accommodate an EdgeTech supplied laptop
personal computer.
The data and control interface between the laptop and the 3100P is via TCP/IP protocols
and may be via wireless or direct cable connections.
Edgetech recommends operating the portable with the cover open and laptop not sitting
on the faceplate. In extreme heat conditions a fan is suggested to move air across the
faceplate.
990-0000058-1000
3
1
0
0
3
1
0
0
Rev F
P
-
T
O
P
S
I
D
E
P
R
O
C
E
S
S
O
R
P
-
T
O
P
S
I
D
E
P
R
O
C
E
S
S
O
R
Page 13
