To connect and attach the tow cable to the tow vehicle:
1.
Verify that the tow cable is not connected to the 3100P topside.
2.
Coil the tow cable in a figure eight configuration.
3.
Verify that the tow cable and tow vehicle connectors are free of corrosion or dirt. If
dirty, clean them with an alcohol wipe.
4.
Apply a thin film of silicone grease to the pins of the tow vehicle tow cable connector
(see "Inspecting and Cleaning the Underwater Connectors" on page 4-2).
5.
Mate the connectors by pressing them firmly together. Do not wiggle the connectors.
6.
Mate the connector locking sleeves.
7.
Connect the eyelet of the cable grip to the shackle on the tow bridle and secure them
with seizing wire or a tie wrap.
8.
Secure the tow cable to the tow bridle using tie wraps. Electrical tape can also be
used for this purpose.
9.
Secure the cable pigtail to tow bridle ensuring that there is proper strain relief and that
the connector does not strum or move in the water current.
990-0000058-1000
3
1
0
0
3
1
0
0
Rev F
P
-
T
O
P
S
I
D
E
P
R
O
C
E
S
S
O
R
P
-
T
O
P
S
I
D
E
P
R
O
C
E
S
S
O
R
Page 40
