Nmea Approved Sentence Structure; Table 4-1 Serial Port Configuration Settings - Edgetech Model 3100P Sub-bottom Sonar System User Manual

Several of the messages conform to the NMEA 0183 protocol. For additional
information refer to:
NATIONAL MARINE ELECTRONICS ASSOCIATION
STANDARD FOR INTERFACING MARINE ELECTRONICS NAVIGATIONAL
4.3.

NMEA Approved Sentence Structure

The following provides a summary explanation of the approved sentence structure:
$aabbb,c---c*hh<CR><LF>
990-0000058-1000

Table 4-1 Serial Port Configuration Settings

Interface USB to RS-232
Com Port 4
Baud Rate 4800
Data Bits 8
Start Bits 1
Stop Bits 1
Parity None
Handshaking None
NMEA 0183
DEVICES
Version 2.00
January 1, 1992
Rev F
3 1 0 0 P - T O P S I D E P R O C E S S O
3 1 0 0 P - T O P S I D E P R O C E S S O
Page 25
