2.1.3.
Environment
Open Cover Operating Temperature: 0°C to 40°C (32°F to 104°F) (shade conditions)
Storage Temperature : -20°C to 60°C (-4°F to 140°F)
Relative Humidity : Operating 0 to 80% (non-condensing), Non-operating 0 to 100%
2.1.4.
Power requirements
DC Input : 12 to 15 VDC
AC Input : 120/240 VAC (Auto-ranging)
CONDITIONS WATTS DC AMPS AC AMPS
Peak power (on startup) 300 Watts 20 Amps at 12 VDC 2 Amps at 120 VAC
Average operating power 48 Watts 4 Amps at 12 VDC 0.4 Amps at 120 VAC
2.2.
Tow Vehicle Interface
Tow Vehicle Power : 12V
Transmit/Receive Signals : Analog
Tow Cable: 35 meter Kevlar tow cable standard. 75 meter maximum length.
2.2.1.
3100P Topside/Notebook Computer Interfaces
Ethernet LAN : 100BaseT, TCP/IP
Wireless Ethernet : 802.11b/g
2.2.2.
Laptop Specifications:
Due to continuous product evolution in this area a firm specification cannot be provided.
The nominal specification for the EdgeTech supplied in the following table.
Laptop Specifications
Notebook computer
990-0000058-1000
Table 2-1 Laptop Specifications
Sony Vaio-FS540P, or equivalent
Rev F
3
1
0
0
P
-
T
O
P
S
I
D
E
P
R
O
C
E
3
1
0
0
P
-
T
O
P
S
I
D
E
P
R
O
C
Description
