5.
Tow Cables
5.1.
Tow Cable Characteristics
The physical and electrical characteristics contained in this document are believed to be
reliable and are derived from vendor-supplied data based upon industry standards.
Element #1: One shielded twisted pair #16 AWG
Element #2: One shielded twisted pair #20 AWG
Element #3: One shielded twisted pair #20 AWG
Strength Member:
Nominal Cable Weight: 30.8 kg per 100 m (207 lb/1000 ft.)
Voltage Rating: 600 Volts.
Bending Radius: 10cm (4 in)
Standard Length: 35 meters (115 feet)
5.2.
AC power Cable
The supplied 2 meter AC Power Cable is used to connect the 3100P Topside Topside to
an AC power source. The source may be 50/60Hz and either 120 or 240 Volts (nominal).
The AC Power color code for the cable is:
Black = Live 120 to 240 VAC
White = Neutral
Green = Ground
990-0000058-1000
1600 kg (3500 lb.) minimum breaking strength
295 kg (650 lb.) working strength.
Rev F
3
1
0
0
P
-
T
O
P
S
I
D
E
P
R
O
C
E
S
S
O
3
1
0
0
P
-
T
O
P
S
I
D
E
P
R
O
C
E
S
S
O
Page 36
