Appendix C: Module Specifications and Features
Main Fire Alarm Chassis (MCC-1024-6[SA])
General
• Eight supervised Style B (Class B) or 4 Style D (Class A)
initiating circuits; fully configurable. Terminals are labelled
"INI". initiating circuits are Compatibility ID "A".
• Power Limited: 22 VDC, 3 mA standby, 5 mV ripple, 50 mA
max. (alarm)
• Four Style Y or Z (Class B or A) indicating circuits;
configurable as strobes or audibles. Terminals are labelled
"IND".
• Power Limited: 24 VDC unfiltered, 1.7 amps @ 49 C per
circuit
•
Up to two circuit adder modules may be added
•
Displays and disconnect switches for up to 24 circuits.
• Optional PR-300 City Tie Module
• Auxiliary power supply (for remote annunciators). Terminals
are labelled "AUX PWR".
• Power Limited: 24 VDC unfiltered, 1.7 amps @ 49 C
• Two Resettable 4-Wire Smoke Supplies. Terminals are
labelled "4-WIRE"
• Power Limited: 22 VDC, 200 mA each max., 300 mA total
max, 5 mV ripple
• 1 RS-485 Connection for Remote Annunciators or interface
to Audio Systems. Power Limited to 300 mA. Terminals are
labelled "RS485"
Micro-controller-based design
Fully configurable from front panel
Full walk test function
Auxiliary relays (resistive loads)
Must be connected to a listed power limited source of supply.
Terminals are labelled "ALARM, TROUBLE, SUPV".
Common alarm:
Form C, 1 Amp, 28 VDC
Common Supv:
Form C, 1 Amp, 28 VDC
Common Trouble:
Form C, 1 Amp, 28 VDC
Electrical Ratings
AC Line Voltage:
120V 60Hz / 240V 50 Hz
2A / 1A primary
Power supply ratings:
6 Amps. max. (secondary)
For indicating circuits:
24VDC unfiltered, 5 Amps. max.
Battery:
24VDC, Gel-Cell/Sealed Lead-Acid
Charging capability:
10-24 AH batteries
Current Consumption: standby: 200 mA alarm: 350 mA
Polarity Reversal and City Tie Module (PR-300)
Supervised city tie - not power limited
24VDC unfiltered, 210 mA max., Trip coil: 14 ohms.
Terminals are labelled "City Tie".
Polarity reversal power limited
Terminals are labelled "Polarity Reversal".
24VDC open
12VDC @ 3.5 mA, 8 mA max. (shorted)
Current Consumption: standby: 35 mA alarm: 300 mA
Main Fire Alarm Chassis (MCC-1024-12[SA])
Same as MCC-1024-6(S) except for
AC Line Voltage:
120 V 60Hz / 240V 50Hz
4A / 2A primary
Power Supply ratings: 12 amps. max. (secondary)
For indicating circuits: 24VDC unfiltered, 10 Amps. max.
Battery:
24VDC, Gel-Cell/Sealed Lead-Acid
Charging capability:
17-40 AH batteries
Current Consumption: standby: 200 mA alarm: 350 mA
Expander Chassis (ECH-1048)
Up to six circuit adder modules may be added.
Displays and disconnect switches for up to 48 circuits.
Current Consumption: standby: 20 mA alarm: 20 mA
Digital Communicator Module (UDACT-300ASUDACT-
300A)UDACT-300A
UDACT - "Digital Alarm Communicator Transmitter" using Ademco
Contact ID and SIA-DCS Protocols
See Mircom document LT-888for further information
Current Consumption: standby: 45 mA alarm: 120 mA
Detection Adder Module (DM-1008A)
Eight supervised Class B (Style B) or four Class A (Style D) initiating
circuits; fully configurable. Terminals are labelled "INI". Initiating circuits
are Compatibility ID "A".
Power Limited:
22VDC, 3 mA standby, 5mV ripple, 50 mA max.
(alarm)
Current Consumption: standby: 80 mA alarm: 100 mA
Signal Adder Module (SGM-1004A)
Four Class B or A (Style Y or Z) indicating circuits; configurable as
strobes or audibles. Terminals are labelled "IND".
Power Limited:
24 VDC unfiltered, max. 1.7 amps @ 49C per
circuit
Current Consumption: standby: 35 mA alarm: 150 mA
Relay Adder Module (RM-1008A) (resistive loads)
Must be connected to a listed power limited source of supply. Terminals
are labelled "RLY".
Eight fully configurable Form C indicating.
Form C, 1 amp., 28 VDC (resistive loads)
Current Consumption:
standby: 25 mA
alarm: 150 mA
System Model: FA-1000 Series Fire Alarm Control Panel
System Type: Local, auxiliary (using PR-300), remote protected
premises station (using PR-300 or UDACT-300A), central station
protected premises (using UDACT-300A).
Type of Service: A, M, WF, SS
Type of Signalling: Non-Coded
Applicable Standards: NFPA 70 and 72, UL-864, ULC S-524, ULC S-
527
FA-1000 Installation and Operation Manual
57
